TOPJOB S S
®
Pluggable Diode Modules and Empty Component 1
Plug Housings on Through Terminal Blocks 2.5 (4) mm², 2002 Series 91
Diode module
with 1N4007 diode as free-wheeling diode 1
U N 250 V, U RM 1000 V
I N 1 A
53,3 mm/2.1 in
Plug width 10.4 mm / 0.409 in

1 2 3 1 Length of 2002-1201: 48.5 mm / 1.91 in
Similar to a push-in jumper, these diode modules are sim- 2-conductor carrier terminal block
ply pushed into the contact slots of the current bars for two 2 Length of 2002-1301: 59.5 mm / 2.34 in
adjacent through terminal blocks. 3-conductor carrier terminal block

This offers the following advantages: 3 Length of 2002-1401: 70 mm / 2.76 in
· These modules are suitable for all 2001 to 2006 4-conductor carrier terminal block
Series through terminal blocks equipped with jumper 4 See application notes for:
slots (please note the module‘s width). Colored push-in type jumper bars, page 101
· Easily retrofit terminal blocks with diode modules. Staggered jumper, page 104
Push-in type wire jumper, page 102
Accessories

Insulation stop,
5 pcs/strip,
0.75 - 1 mm²
dark gray 2002-172 200 (8x25)
Pack. Protective warning marker,
Item No. Unit with high-voltage symbol, black,
Diode module, for 5 terminal blocks
with 1N4007 diode as free-wheeling diode, max. operat- yellow 2002-115 100 (4x25)
ing temperature: 85°C, Plugging a diode module into a through terminal block. Push-in type wire jumper,
10.4 mm wide Additional advantages: 4 insulated,
gray 2002-880/1000-411 50 · Separation into functional and wiring level I N 18 A,
· Modules can be replaced quickly by other types of wire size 1.5 mm²
Empty component plug housing type 4, modules L = 60 mm 2009-412 100 (10x10)
2-pole, · Solder-free assembly of diodes, resistors, etc. L = 110 mm 2009-414 100 (10x10)
10.4 mm wide L = 250 mm 2009-416 100 (10x10)
gray 2002-880 50
Through Term. Blocks and Accessories Push-in type jumper bar, insulated,
Appropriate marking system: 4 I N 25 A,
light gray
WMB/Marking strips 2-way 2002-402 200 (8x25)
2-conductor through terminal block, 3-way 2002-403 200 (8x25)
1 0.25 - 2.5 (4) mm² / AWG 22 - 12 4-way 2002-404 200 (8x25)
Terminal block width 5.2 mm / 0.205 in 5-way 2002-405 100 (4x25)
gray 2002-1201 100 6-way 2002-406 100 (4x25)
End and intermediate plate, 0.8 mm thick 7-way 2002-407 100 (4x25)
orange 2002-1292 100 (4x25) 8-way 2002-408 100 (4x25)
gray 2002-1291 100 (4x25) 9-way 2002-409 100 (4x25)
10-way 2002-410 100 (4x25)
3-conductor through terminal block, Push-in type jumper bar, insulated,
2 0.25 - 2.5 (4) mm² / AWG 22 - 12 Opening the cover via operating tool I N 25 A,
Terminal block width 5.2 mm / 0.205 in (blade width 2.5 mm). light gray
gray 2002-1301 100 from 1 to 3 2002-433 200 (8x25)
End and intermediate plate, 0.8 mm thick from 1 to 4 2002-434 200 (8x25)
orange 2002-1392 100 (4x25) from 1 to 5 2002-435 100 (4x25)
gray 2002-1391 100 (4x25) from 1 to 6 2002-436 100 (4x25)
from 1 to 7 2002-437 100 (4x25)
4-conductor through terminal block, from 1 to 8 2002-438 100 (4x25)
3 0.25 - 2.5 (4) mm² / AWG 22 - 12 from 1 to 9 2002-439 100 (4x25)
Terminal block width 5.2 mm / 0.205 in from 1 to 10 2002-440 100 (4x25)
gray 2002-1401 100
End and intermediate plate, 0.8 mm thick Staggered jumper,
orange 2002-1492 100 (4x25) 4 insulated,
gray 2002-1491 100 (4x25) I N 25 A,
light gray
Insulation stop, 2-way 2002-472 100 (4x25)
5 pcs/strip, 3-way 2002-473 100 (4x25)
0.25 - 0.5 mm² 4-way 2002-474 100 (4x25)
light gray 2002-171 200 (8x25) 5-way 2002-475 50 (2x25)
Certification organizations can be found in the overview on pages 622 and 623.
