58 Control Valves ¶ ,_OH\Z[ =HS]LZ

4 1 :LYPLZ ,_OH\Z[ =HS]LZ

*SPWWHYK»Z 4 1 :LYPLZ ,_OH\Z[ =HS]L VɈLYZ H ]HYPL[` VM KLZPNU MLH[\YLZ HUK WYV]PKLZ MHZ[ YLZWVUZL [PTLZ HUK OPNO ÅV^
with G1/4 ports. This compact poppet type valve is constructed of brass and is 100% tested to assure the highest qua-
lity. The M-JEV’s primary function is to increase cylinder speed. However, it also enables the use of smaller directional
valves, longer control lines and can be used as a shuttle valve.

Inlet Thread Size Outlet Thread Size
2 - G 1/8 2 - R 1/8
4 - G 1/4 4 - G 1/4 / R 1/4

M - - -

J-Series Exhaust Valve Inlet Thread Type Outlet Thread Type Exhaust
JEV - Inlet-to-Outlet 90° F - Female Thread M - Male Thread N - Unthreaded
Orientation F - Female Thread Exhaust

G1/8 Ports In-Line

4.1 dia. exhaust
holes (2)
G1/8
R1/8
inlet
outlet
17.5
hex.
40.4

Part No.
M-JLEV-F2M2-N
