COMMERCIAL/INDUSTRIAL USE








        Parker BVC fi lter housings


        Effective fi ltration and disinfection for

        potable water






        Designed for small and medium
        size commercial and potable water
        applications.
        Features


        • 304 SS vessel construction
        • Electropolished and passivated
        • Accepts either sediment removal or
          BVC micro-organism fi lter cartridge
        • Flow rates up to 40 gpm
        • Conforms to NSF/ANSI Std 61
        • Min./max. working pressure:
          40 psi (2.8 bar) /125 psi (8.6 bar),
          non shock
        • Temperature: 35-200° F (2-76° C)

        Markets
                                                                                  Pretreatment Guidelines for BVC
        • Beverage plants                    • Supermarkets                       Microorganism Reduction Cartridge:
        • Restaurants                        • Vegetable packaging                • Turbidity <=1 NTU
        • Manufacturing/Rinsing              • Water re-use                       • Hardness:  Recommended <7 gpg
        • Bottled water                      • Hotels                             • TOC <50 mg/L
        • Water jet cutting                  • Water parks                        • pH 5-9.5
        • Food processing                    • Municipal pools                    • Iron <0.3 ppm
        • Remediation                        • Cruise ships                       • Manganese <0.05 ppm
        • Quench water                                                            • TDS <30 g/L
        • Offshore oil and gas rigs                                               • TSS low as possible to extend BVC life
                                                                                  • Bacteria, Virus, Cysts reduction is
        Contact Information                                                         greater than 1 million organisms per
                                                                                    gpm of design fl ow rate at end of life
        Parker-Hannifi n Corporation           Single cartridge housing
        domnick hunter Process Filtration
        2340 Eastman Avenue                    Flow Rate   Model No.  Filter Cartridge               Connection Size
        Oxnard, California, USA 93030                      BVCH-20SG  Sediment reduction cartridge      1˝ NPTM
                                                                      BVC-4524-SED                     Inlet/Outlet
        toll free: +1 877 784 2234            Up to 20 gpm            Micro-organism reduction cartridge   1˝ NPTM
        phone: +1 805 604 3400                             BVCH-20MG  BVC-4524-MIC                     Inlet/Outlet
        dhpsales.na@parker.com                                        Sediment reduction cartridge      1½˝ NPTM
                                                           BVCH-40SG
        www.parker.com/processfi ltration      Up to 40 gpm            BVC-4540-SED                     Inlet/Outlet
                                                                      Micro-organism reduction cartridge   1½˝ NPTM
                                                           BVCH-40MG
                                                                      BVC-4540-MIC                     Inlet/Outlet
                                             © 2013 Parker-Hannifi n Corporation         domnick hunter Process Filtration - North America
                                             For User Responsibility Statement, see www.parker.com/safety  All Rights Reserved
                                                                                                      GL_BVC CH  08/13 Rev. A
