PVC PVC Split Cable Guard

MSHA

Series 7575

Series 7575 is a guard/harness to protect cables and hoses from abrasion and debris in
underground mining applications. The construction features a smooth tube that prevents
snagging and a uniformly split wall for easy installation of cables, hoses and other materials.
The translucent, flame resistant PVC material meets MSHA requirements, is abrasion
resistant and permits visual observation of the contained cables and hoses.

Tube: Translucent PVC; smooth
Reinforcement: White PVC helix
Cover: Translucent PVC; corrugated
Temp. Range: +14°F to +140°F (-10°C to +60°C)
Brand Method: Black ink
Brand Example: PARKER 7575 CABLE GUARD MSHA # MADE IN GREECE
(DATE CODE)
Industry Standards: MSHA
Applications: • Cable and hose bundle protection
• Protective cover for mine supply lines
• General industrial, mining
Vacuum: Not recommended
Compare to: Kuriyama CG-SL, Novaflex 143, Veyance Spiraflex
Packaging: Coils

Part ID ID OD OD Approx Approx Std Pack Stock
Number (in) (mm) (in) (mm) Wt Wt Qty Status
(lbs/ft) (kg/ft) (ft) **
7575-3000 3 76.2 3.268 83.0 4.20 1.91 100 Y
** Stock: “Y” indicates stocked item; “N” indicates non-stocked item. Stock status subject to change.
Contact Parker Customer Service.
