MC-VHD-36
91090 Series
Vertical Hold Down Clamps | Product Overview
Features: Applications: Also Available:
• Front flange mount • Assembly & test See page MC-ACC-1 for accessories
• Accepts M8 or 5/16” spindle accessory • Checking fixtures
(not supplied) • Light machining
• Woodworking
91090
Front Flanged Base
Open Bar
Technical Information | Dimensions
Recommended Accessories
Max. Holding Clamp Bar Handle Bolt Spindle Flanged
Model Opening Opening Weight
Capacity Retainer Assembly Washers
(+10°) (+10°)
91090 1710 N [385 lbf] 100° 60° 0,37kg [0.81lbs] --- 507208-M 507107
[0.31]
8
[0.13] [0.62]
3,2 [2.40] 15,8
60,9
[0.63]
16
[0.28] [7.89]
Ø 7 200,4
[3.35] [2.72]
[1.46] 85,0 69
37
[3.02]
[1.31] [0.79] 76,7
33,4 20 [4.72]
[1.98] 120 mm [INCH] mm [INCH]
50,4
THIRD ANGLE FIRST ANGLE
[4.72] PROJECTION PROJECTION
120
Dimensions and technical information are subject to change without notice MC-VHD-36
