K Series Linear Actuators

Foot Mount KSFM-60 KSFM-75 KSFM-90
in 1.536 1.969 2.502
A
mm 39.03 50.00 63.55
D
A F in 4.0 4.921 5.669
B
mm 101.6 125.00 144.00
in 0.375 0.512 0.750
C mm 9.53 13.00 19.05
B in Ø 0.260 Ø 0.354 Ø 0.433
D
mm 6.60 9.00 11.00
in 1.50 1.969 1.750
E mm 38.10 50.00 44.45
C
E in 3.250 3.937 4.724
F
Mounting position shown for dimensions only. mm 82.55 100.00 120.0
Feet may be positioned on any side, at any distance.
Front Flange KSFF-60 KSFF-75 KSFF-90
in 1.772 1.969 2.480
A
mm 45.00 50.00 63.00
in 2.559 3.150 3.780
B
mm 65.00 80.00 96.00
B A in Ø 0.354 Ø 0.354 Ø 0.480
C
mm 9.00 9.00 12.20
in 3.543 3.937 4.961
D
C D mm 90.00 100.00 126.00
F
E E in 4.528 5.118 6.496
mm 115.00 130.00 165.00
in 0.394 0.591 0.750
F
mm 10.00 15.00 19.05

End Angles Inline KSEA-60 KSEA-75 KSEA-90
Parallel KSEP-60 KSEP-75 KSEP-90
in 1.400 1.968 2.219
A
A mm 35.55 50.00 56.35
in 3.543 2.953 3.543
B
mm 90.00 75.00 90.00
in 0.140 0.250 0.250
B D C mm 3.56 6.35 6.35
in 2.835 1.969 2.480
D
mm 72.00 50.00 63.00
C E F E in Ø 0.260 Ø 0.354 Ø 0.472
G mm 6.60 9.00 12.00
in 0.856 1.083 1.319
F mm 21.74 27.50 33.50
K60 Maximum Allowable Actuator Force = 1350 lbs in 1.001 1.575 1.969
K75 Maximum Allowable Actuator Force = 2000 lbs G
K90 Maximum Allowable Actuator Force = 1350 lbs mm 25.44 40.00 50.00
