Page 20 - Eaton - Automatic self-cleaning family

Tubular Backwashing Filter

Cake formation
Process liquid During backwash, increases filtration
flows into the triggered by time or efficiency
housing inlet at its pressure differential, a
base and passes valve switches one Whereas the filtration media
across the filter station’s flow from the provides some of the filtration
media from the inlet header to the drain action, collected contaminants
outside inward. header and the direction further increase efficiency. We call
Because of this of the flow is reversed in this phenomenon “cake formation.”
flow path, contami- the filter tube, dislodging The collected solids, or “cake,”
nants collect on the contaminants from the trap additional contaminants. The
outside of the filter media surface. The source key to making this principle work
element slowly of the cleaning fluid may is timely cleaning—too soon and
forming a cake, be a diversion of process you lose the benefit, too late and
removing smaller fluids (internal back- the system flow becomes hindered.
particles. washing) or an external
source (external back- Eaton’s filtration systems come
washing). factory pre-set to backwash when
the differential pressure from inlet
Contaminants and the to outlet reaches 15 psi (1 bar)—
fluids used for cleaning typically the optimum time to
are expelled through the initiate backwashing, although
drain header at the base this is adjustable.
of the unit. Once back-
washing is complete, the
flow is reversed again and
normal filtration resumes.

For liquid filtering applications
that require unattended operation,
maximum uptime, and solids removal
from 1 to 1,700 microns, the Eaton The revolutionary
F-Series family of filter systems Eaton AFR-Series
delivers unbeatable performance. delivers high-
flow filtration of
water-like liquids
at retentions as
low as 1 micron
—in a compact
one-square-meter
footprint.
When your application demands high-
pressure operation—up to 1,000 psi
(69 bar)—and scalable flexibility, the
Eaton AFC-Series is optimal. Systems
are available in single, duo, and
multiplex configurations to meet your
application and business demands.
