                                                                                              Standard Bag
          Fulfl o  Filter Bags
                                                                                              Flow Factors
          SPECIFICATIONS                      Effective Removal Ratings                      Rating   Flow
          Maximum Recommended                 0.5μm to 800μm                                 (µm)    Factors
          Operating Conditions
                                              Bag Media Selection                              1     0.00083
          Temperature:                        Mono-fi lament Mesh:                              3     0.00059
          Polyester: 275°F (136°C)            Single strand nylon with retention ratings
          Polypropylene: 200°F (94°C)         from 100μm to 600μm                              5     0.00044
          Monofi lament Nylon Mesh: 275°F (136°C)                                              10     0.00029
                ®
          Nomex : 425°F (220°C)               Glazed Felt:
                                              In polypropylene or polyester felts, the sur-   25     0.00017
          Multifi lament Polyester Mesh:
          275°F (136°C)                       face fi bers are melt bonded to one another,     50     0.00013
                                              reducing the possibility of fi ber migration
          Flow Rate: (Per single length)                                                      75     0.00008
                                              Multi-fi lament Mesh:
          Standard Bag: 80gpm (303 lpm)       Strong fabric woven from twisted strands.       100    0.00007
          Change-out ΔP: 35psi (2.4bar)       Particle retention ratings from 150μm to   Flow Rate and Pressure Drop Formulas
                                              800μm
          Pressure: 70psid (4.8bar)                                               Flow Rate (gpm) =  Clean ΔP x Length Factor
                                              High Temperature Nomex ®                            Viscosity x Flow Factor
          Size
                                                                                  Clean ΔP = Flow Rate x Viscosity x Flow Factor
          C1: 7.5˝ X 17.5˝                    Standard Seal (no seal option specifi ed)
                                                               ™
          C2: 7.5˝ X 31.5˝                    C = Plastic Quik-Seal  Ring                        Length Factor
          G1: 7˝ X 17.5˝                      (polypropylene for P felt and polyester  Notes:
          G2: 7˝ X 31.5˝                      for PE felt)                        1. Clean ΔP is psi differential at start.
                                                                                  2. Viscosity is centistokes. Use Conversion Tables for other units.
                                              G = Galvanized Steel Ring           3. Flow Factor is ΔP/GPM at 1cks for single length bag.
                                                                                  4. Length Factors convert fl ow or ΔP from single length bags.
                                                                                    Use length factor or 1 for single length and a factor of 2 for
                                                                                    double length.




          Ordering Information

           Polypropylene, Polyester Felt Bags Note: C-Style Bags for Parker housings / G-Style Bags for Competitor housings


            C                             —                          G                            —


                                                                            Bag       Polypropylene Media  Seal Options
                   Bag        Polypropylene Media  Seal Options
                                                                         STYLE  SIZE        1μm         Top  Sealing
                STYLE  SIZE        1μm                                                               Q
                                             F  Flex Band Seal                                          Plastic Ring
                                                                                1           3μm
                       1           3μm                                    G
                 C                                                              2           5μm
                       2           5μm
                                                                                      P     10μm
                              P    10μm
                                                                                            25μm
                                   25μm
                                                                                            50μm
                                   50μm
                                                                                           100μm
                                   100μm
                                                                                       Polyester Media
                              Polyester Media
                                                                                            1μm
                                   1μm
                                                                                            3μm
                                   3μm
                                                                                            5μm
                                   5μm
                                                                                            10μm
                                   10μm
                                                                                      PE    25μm
                             PE    25μm
                                                                                            50μm
                                   50μm
                                                                                            75μm
                                   75μm
                                                                                           100μm
                                   100μm
                                                                                           200μm
                                   200μm
                                                             86
