HAND TOOLS

H-2008 Dual Feed Grommeting Press

The H-2008S dual feed, auto-punch grommeting machine uses separate cutting
and setting die on a fast, rotating turn-table. Specifications
The washer feeding track does not have a bend in it and it uses a turn-table to feed u Throat Depth: X”
the washer to the die set instead of using a pushrod to push the washer forward. u Power: 110/220v
The H-2008S was designed to set all kinds of grommets such as brass, steel, u Dimensions: 27” x 25” x 52”
aluminum and poly carbonate. It is capable of inserting up to 2000 grommets per u Net Weight: 396 lbs.
hour as it punches a hole, sets a grommet and is ready to go again in just over a
second.
Available with push button or pedal actuation, the H-2008S comes equipped
with a material edge guide and standard safety features such as a die shield and
surrounding die table.
u Feeds both grommet & washer
u Punches hole for standard grommets Item
u Designed for smooth feeding
u Feeding Tracks HIK#H-2008S

Hiker H-901F/B Grommeting Hand Press

The HIKER H-901 hand press has interchangeable dies are so you can insert several
types and sizes of grommets with the same press. The lower die is adjustable, Die Sets
which provides a consistent, quality setting in various material thicknesses. It was
designed to produce up to 6 times more cutting and closing pressure than other Item Size
competing presses. Use with flat washers, turn-over washers, spur washers and
thin or thick material. HIK#DIE-#0 #0
HIK#DIE-#1 #1
HIK#DIE-#2 #2
u Interchangeable Die Specifications
u Adjustable Lower Die HIK#DIE-#3 #3
u Professional Grade u Throat Depth: 2 3/4” HIK#DIE-#4 #4 Item
u Inserts eyelets as small as 1/16” u Height: 11”
u Inserts self-piercing grommets as large as 5/8” u Weight: 16 lbs. HIK#DIE-#5 #5 HIK#H-901

Grommets

HIKER’s self-piercing grommets are manufactured in an ISO 9002 certified
environment with only the highest quality raw materials. No other company in
North America has as more sizes and types of self-piercing grommets
Dual Feed Grommets
Item Size Finish Grommets
HIK#SPW-RF#2/BLACK #2 Black Item Size
HIK#SPW-RF#2/BRASS #2 Brass HIK#H307AS #3
HIK#SPW-RF#2/NICKEL #2 Nickel HIK#H307AS1/2 #4
HIK#SPW-RF#2/STAINLESS #2 Stainless HIK#H307ASSX #5
