P. 246

Hardness testing and metallography
         Mobile hardness testers


                         Mobile rebound hardness tester D200                                         DIN 50156
                          Separate impact unit type D and wireless printer
         Application:                     Advantage:
         For determining and directly displaying hardness   ƒ Standard conversion tables integrated in the
         values in line with HL (Leeb), HB, HV, HRB (Rockwell   device are split into ten material groups
         B), HRC, HS (Shore) and tensile strength in N/mm .   ƒ Hardness values are immediately displayed
                                       2
         Suitable for large components made from steel,   according to a pre-defined hardness scale
         stainless steel, cast iron, aluminium alloys, brass,   ƒ Wireless printer for documenting individual meas-
         bronze and copper forged alloys from a mass of   urements or measurement series
         approx. 5 kg upwards.
                                          scope of supply and services:
         Execution:                       Display unit, separate impact unit, hardness refer-
         ƒ Separate impact unit type D, HM ball diameter   ence block, wireless printer, charger, cleaning
          3 mm                            brush, USB cable, stylus, software and transport
         ƒ Backlit, 3.9”, colour, LCD touch screen display   case.
          (240 x 320 pixels)
         ƒ Individual value and mean value display, absolute  Notes:
          range, no. of measurements      Components with a reduced mass of < 5 kg must be
         ƒ Dynamic rebound method in line with ASTM A956   suitably positioned vibration-free on a large metal
                                          subsurface.
          and DIN 50156
         ƒ Probe test direction can be selected depending on   Technical Data:
          the position of the surface being measured  ƒ Measuring range (low-alloy steel): 560-950 HL |
         ƒ internal memory for 500 measurements  81-955 HV | 81-654 HB | 32.5-97.9 HS | 38.4-
         ƒ Wireless printer                 99.5 HRB | 20-68.4 HRC | 375-2639 N/mm 2
         ƒ Material groups: 1.) Low-alloy/unalloyed steel,   ƒ Hardness accuracy: ± 6 HL
          2.) Tool steel, 3.) Corrosion-resistant steel, 4.)   ƒ Hardness revolution: 1 HL | 1 HB | 1 HV | 1 N/
                                              2
          Grey cast iron GG, 5.) Spheroidal cast iron, 6.)   mm  | 1 HS | 0.1 HRC | 0.1 HRB
          Aluminium cast alloys, 7.) Brass, 8.) Bronze, 9.)   ƒ Rechargeable battery/battery designation: 1.2 V
          Copper forged alloys, 10.) Forged steel  NiMH AAA
                                          ƒ Length x width x height: 130 x 87 x 28 mm
                             095
                   Ident. No.
          42160...  Unit price, €  O. R.
         Prod. Gr. 423
    Testing equipment
                         Mobile rebound hardness tester D400                                         DIN 50156
                          Separate impact unit type D
         Application:                     Advantage:
         For determining and directly displaying hardness   ƒ Standard conversion tables integrated in the
         values in line with HL (Leeb), HB, HV, HRB (Rockwell   device are split into nine material groups
         B), HRC, HS (Shore) and HRA. Suitable for large   ƒ Hardness values are immediately displayed
         components made from steel, stainless steel, cast   according to a pre-defined hardness scale
         iron, aluminium alloys, brass, bronze and copper
         forged alloys from a mass of approx. 5 kg upwards.  scope of supply and services:
                                          Display unit, separate impact unit D, hardness refer-
         Execution:                       ence block with workshop certificate (HLD value),
         ƒ Separate impact unit type D, HM ball diameter   software with connecting cable, batteries, coupling
          3 mm                            compound, cleaning brush and transport case.
         ƒ Backlit LCD display (128 x 64 pixels)
         ƒ Individual value and mean value display, absolute  Notes:
          range, no. of measurements      Components with a reduced mass of < 5 kg must be
         ƒ Dynamic rebound method in line with ASTM A956   suitably positioned vibration-free on a large metal
                                          subsurface.
          and DIN 50156
         ƒ Probe test direction can be selected depending on   Technical Data:
          the position of the surface being measured  ƒ Measuring range (low-alloy steel): 200-900 HL |
         ƒ internal memory for 1974 measurements  80-940 HV | 80-650 HB | 32-100 HS | 60-100
         ƒ Material groups: 1.) Low-alloy/unalloyed steel,   HRB | 20-68 HRC | 59-86 HRA
          2.) Tool steel, 3.) Corrosion-resistant steel, 4.)   ƒ Hardness accuracy: ± 4 HL (0.5% at 800 HL)
          Grey cast iron GG, 5.) Spheroidal cast iron, 6.)   ƒ Hardness revolution: 1 HL | 1 HB | 1 HV | 1 HS |
          Aluminium cast alloys, 7.) Brass, 8.) Bronze, 9.)   0.1 HRC | 0.1 HRB
          Copper forged alloys            ƒ Rechargeable battery/battery designation: 1.2 V
                                            Mignon AA
                                          ƒ Length x width x height: 122 x 65 x 22 mm
                                          ƒ Memory (measurements): 1974 PCS
                   Ident. No.
                             115
          42160...  Unit price, €  O. R.
         Prod. Gr. 423
