Milling tools monoblock \ Solid carbide mills for machining hard materials up to 65 HRC
Type H
Surface TiSiN
Tool holding device HA parallel shank
Tolerance of cutting edge Ø f8
Tolerance of shank Ø h6
Z (PCS) fz hard 65 HRC ˜ 16933...
(mm) Ident. No.
mm mm mm mm
3 6 54 6 2 0.019 009 ●
4 7 54 6 2 0.019 012 ●
6 10 54 6 2 0.048 015 ●
8 12 59 8 2 0.06 018 ●
10 14 67 10 2 0.07 021 ●
12 16 74 12 2 0.08 024 ●
16 20 83 16 2 0.09 027 ●
Prod. Gr. 1FQ
Solid carbide radius cutter
2 flutes, TiSiN-coated

Typ Z HA
VHM TiSiN H 2
Application: ƒ type H
Radius cutter in long design for machining materials ƒ 0° chip angle
up to 68 HRC, e.g. in die and mould making. ƒ TiSiN-coated
Execution: ƒ Radius tolerance = +/- 0.005 mm
ƒ solid carbide ultra-fine grain Advantage:
ƒ cutting edge finish ƒ optimum chip removal and temperature resistance
ƒ HA shank in line with DIN 6535 ƒ Maximum service life deu to TiSiN coating
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16933050-074 200 170 140
Type H
Surface TiSiN
Tool holding device HA parallel shank
Tolerance of cutting edge Ø f8
Tolerance of shank Ø h6
Z (PCS) fz hard 65 HRC ˜ 16933...
(mm) Ident. No.
mm mm mm mm
1 3 75 3 2 0.005 050 ●
2 6 80 6 2 0.005 053 ●
3 10 80 6 2 0.019 056 ●
4 13 80 6 2 0.019 059 ●
6 16 100 6 2 0.048 062 ●
8 22 100 8 2 0.06 065 ●
10 25 100 10 2 0.07 068 ●
12 26 100 12 2 0.08 071 ●
16 30 150 16 2 0.09 074 ●
Prod. Gr. 1FQ
Solid carbide radius cutter
4 flutes, TiSiN-coated

Typ Z HA
VHM TiSiN H 4
Application: ƒ type H
Radius cutter in standard design for machining mate- ƒ 0° chip angle
rials up to 68 HRC, e.g. in die and mould making. ƒ TiSiN-coated
Execution: ƒ Radius tolerance = +/- 0.005 mm
ƒ solid carbide ultra-fine grain Advantage:
ƒ cutting edge finish ƒ optimum chip removal and temperature resistance
ƒ HA shank in line with DIN 6535 ƒ Maximum service life deu to TiSiN coating
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16933103-130 200 170 140
Type H
Surface TiSiN
Tool holding device HA parallel shank
Tolerance of cutting edge Ø f8
Tolerance of shank Ø h6
Z (PCS) fz hard 65 HRC ˜ 16933...
(mm) Ident. No.
mm mm mm mm
2 4 54 6 4 0.005 103 ●
3 5 54 6 4 0.019 109 ●
4 8 54 6 4 0.019 115 ●
6 10 54 6 4 0.048 118 ●
8 12 59 8 4 0.06 121 ●
