Page 106 - 2022FittingsCatalog

PUNCH CLAMPS PUNCH CLAMP TOOLS

Clamp Band Part
Part No. I.D. Width Pkg Qty Number Description
PC… PLATED CARBON STEEL PUNCH CLAMPS PUNCH CLAMP TOOLS

PC-3 13 ⁄16" 3 ⁄8" 100
PC-311 1 3 ⁄8" 3 ⁄8" 100 P-38 Economy Tool
PC-4 1" 5 ⁄8" 100
PC-5 1 1 ⁄4" 5 ⁄8" 100
PC-6 1 1 ⁄2" 5 ⁄8" 100
PC-7 1 3 ⁄4" 5 ⁄8" 100
PC-8 2" 5 ⁄8" 100
PC-9 2 1 ⁄4" 5 ⁄8" 100
PC-10 2 1 ⁄2" 5 ⁄8" 50
PC-11 2 3 ⁄4" 5 ⁄8" 50
PC-12 3" 5 ⁄8" 50
PC-14 3 1 ⁄2" 5 ⁄8" 50
PC-16 4" 5 ⁄8" 25 P-1 Service Tool
PC-18 4 1 ⁄2" 5 ⁄8" 25
PC-20 5" 5 ⁄8" 25
PC-24 6" 5 ⁄8" 25
PC-28 7" 5 ⁄8" 25
PC-32 8" 5 ⁄8" 25

PC-S… TYPE 201 STAINLESS STEEL PUNCH CLAMPS

P-1000 Service Tool

11 PC-3S 13 ⁄16" 3 ⁄8" 100
PC-311S 1 3 ⁄8" 3 ⁄8" 100
PC-4S 1" 5 ⁄8" 100
100
5 ⁄8"
1 1 ⁄4"
PC-5S
Clamps & Ferrules PC-7S 1 3 ⁄4" 5 ⁄8" 100
1 1 ⁄2"
PC-6S
100
5 ⁄8"
5 ⁄8"
2"
100
PC-8S
2 1 ⁄4"
PC-9S
100
5 ⁄8"
2 1 ⁄2"
PC-10S
5 ⁄8"
50
5 ⁄8"
PC-11S
50
PC-12S
3"
5 ⁄8"
PC-14S 2 3 ⁄4" 5 ⁄8" 50
50
3 1 ⁄2"
PC-16S 4" 5 ⁄8" 25
PC-18S 4 1 ⁄2" 5 ⁄8" 25
PC-20S 5" 5 ⁄8" 25
PC-24S 6" 5 ⁄8" 25
PC-28S 7" 5 ⁄8" 25
PC-32S 8" 5 ⁄8" 25
