Ex: 02
A DOULE STOREYED RESIDENCE – 01
A site 30m x 15m has a 6m wide road abutting the shortside on the east. Plan a residence in the site
for the following requirements.
Ground floor
2
1. Car porch – 18 m
2
2. Front verandah - 5 m
2
3. Living area – 16 m
2
4. Dining area – 12 m
2
5. Bed room – 15 m
2
6. Toilet for bed – 4 m
2
7. Kitchen – 12 m
2
8. Prayer space – 7 m
2
9. Work area – 8 m
2
10. Toilet in work area – 2.5 m
First floorTwo bed rooms of appropriate sizes with common toilet.
Draw the plan of the building. Draw a section showing maximum details and elevation.
