Page 1473 - Master Catalog 2017, Inch
P. 1473
Modular Drills
™
TOP DRILL M1 Shanks
• Tool body shipped with insert wrench.
Flanged Shank with Flats (SCF)
TOP DRILL M1 • 8 x D • Flanged • Inch
insert blade
order number catalog number D1 D1 max D L1 L3 L4 max L5 LS seat size
4099057 TDM0313R8SCF050 .313 .3343 .5000 3.38 3.16 2.68 .057 1.77 W10
4099058 TDM0335R8SCF050 .335 .3539 .5000 3.50 3.28 2.83 .062 1.77 W11
4099059 TDM0354R8SCF050 .354 .3736 .5000 3.75 3.53 2.99 .065 1.77 W12
4099060 TDM0374R8SCF050 .374 .3933 .5000 4.00 3.78 3.15 .068 1.77 W13
4099061 TDM0394R8SCF063 .394 .4130 .6250 4.13 3.91 3.31 .072 1.89 W14
4099062 TDM0413R8SCF063 .413 .4327 .6250 4.25 4.03 3.46 .076 1.89 W15
4099063 TDM0433R8SCF063 .433 .4524 .6250 4.50 4.28 3.62 .079 1.89 W16
4099064 TDM0453R8SCF063 .453 .4720 .6250 4.63 4.41 3.78 .082 1.89 W17
4099065 TDM0472R8SCF063 .472 .4917 .6250 4.88 4.66 3.94 .087 1.89 W18
4099066 TDM0492R8SCF063 .492 .5114 .6250 5.00 4.78 4.09 .090 1.89 W19
4099067 TDM0512R8SCF063 .512 .5311 .6250 5.13 4.91 4.25 .093 1.89 W20
4099068 TDM0532R8SCF063 .532 .5508 .6250 5.38 5.16 4.41 .098 1.89 W21
4099069 TDM0551R8SCF063 .551 .5705 .6250 5.63 5.41 4.57 .101 1.89 W22
Modular Drills
4099070 TDM0571R8SCF063 .571 .5902 .6250 5.75 5.53 4.72 .104 1.89 W23
4099071 TDM0591R8SCF075 .591 .6295 .7500 6.13 5.91 5.04 .107 1.97 W24
4099072 TDM0630R8SCF075 .630 .6689 .7500 6.50 6.28 5.35 .113 1.97 W25
4099073 TDM0669R8SCF075 .669 .7083 .7500 6.88 6.66 5.67 .121 1.97 W26
4099074 TDM0709R8SCF075 .709 .7476 .7500 7.25 7.03 5.98 .129 1.97 W27
4099075 TDM0748R8SCF075 .748 .7870 .7500 7.50 7.28 6.30 .134 1.97 W28
4099076 TDM0787R8SCF100 .787 .8264 1.0000 7.88 7.66 6.61 .143 2.20 W29
4099077 TDM0827R8SCF100 .827 .8657 1.0000 8.25 8.03 6.93 .151 2.20 W30
4099078 TDM0866R8SCF100 .866 .9051 1.0000 8.63 8.41 7.24 .156 2.20 W31
4099079 TDM0906R8SCF100 .906 .9445 1.0000 9.00 8.78 7.56 .167 2.20 W32
4099080 TDM0945R8SCF100 .945 .9839 1.0000 9.38 9.16 7.87 .173 2.20 W33
4099081 TDM0984R8SCF100 .984 1.0232 1.0000 9.75 9.53 8.19 .178 2.20 W34
widia.com S13
