Hole Finishing
™
ROTAFLEX High-Performance Boring Systems

(continued)

„ Insert Holder Reference Chart

C-Style 70° C-Style 90° S-Style 80° T-Style 90°
12625906700 12625706700 12626006700 12625806800

„ Slide for Micro-Adjustable Cartridges

L1
adjusting fixing hex
order number catalog number mm in screw screw wrench
3864647 SMAC087 19,2 .8 12147665000 12147519100 12148041100

Hole Finishing

widia.com U53
