WELDING SUPPLIES

Industrial Safety Welding Oilfield Construction

J Series E1016 Plugs Cable Lugs

•FeaPtluurgessf:eature a high‑strength locking ring to capture Features:

and secure the insulator to the contact. • Made from copper tubing.
• Extra long barrels for easy soldering or attaching by the swedg‑on process.
• Precision‑machined contacts are constructed from high‑conductivity • Stud holes made especially for welding machines with plenty of clearance.
• Flared ends make it easy to insert the cable in the lug.
brass for superior electro mechanical connections.

• Locked contacts can withstand a pulling force of 1000 lbs.
• Plugs accept a wide range of cable sizes.

SKU Connection Type Cable Cap.
627‑E1016‑8350 Double Set Screw Male Plug #2 ‑ 2/0

Insulated Cable Lugs SKU Cable Cap.
380‑07010 2‑1
Features: 380‑07020
380‑07030 2/0 ‑ 1/0
• Cable lugs give you completely insulated welding machine 4/0 ‑ 3/0

terminal connections, plus quick‑connect convenience.

• Simple and safe.

SKU Connection Type Connector Terminals
138‑14746 Terminal Cover
Features:

• Add on cable.
• Take off cable.
• Change polarity.

Quik-Trik* Cable Connectors SKU Cable Cap.
380‑08030 ‑
•FeaCtaumrelos:ck and locking bar draw together for virtually unbreakable connection.
• Form‑fitted rubber jacket insulator protects against moisture, oil and dirt. International DINSE Type
• Large dome‑nose screw for high‑conductivity connection. Machine Plug Adapters

WELDING SUPPLIES SKU Connection Type Cable Cap. F•eaIntuterrecsh:angeable with M.K.
138‑14733 Single Dome‑Nose 2/0 AWG ‑ 1/0 AWG • Product (042‑465).
138‑14734 Single Dome‑Nose 4/0 AWG ‑ 3/0 AWG • Simple and safe.
138‑14737 Single Dome‑Nose 2/0 AWG ‑ 1/0 AWG
138‑14739 Single Dome‑Nose 2/0 AWG ‑ 1/0 AWG

SKU Connection Type
380‑05335 Dinse Male Adapter; Dinse Female Adapter
380‑05330
Dinse Male Adapter

Cable Connectors International DINSE Type Machine Plugs

•FeaCtaumreasc: tion design of male half connector pulls the two halves together. •FeaStiunrgeles:oval‑point screw cable connection.
• Connector covers are molded form a special • Male .508 (12.9mm) diameter.

heat‑ and cold‑resistant material.

• Covers have no metal liner to rust or corrode.
• Metal parts are precision machined with heavy

specially shaped brass extrusion.

SKU Connection Type Cable Cap. SKU Connection Type Cable Cap.
380‑05060 Double Oval‑Point Screw 4/0 ‑ 3/0 380‑05303 Single‑Oval‑Point Screw 4 ‑ 1/0
380‑05040 Single Oval‑Point Screw 4 ‑ 1/0
380‑05050 Single Oval‑Point Screw 2/0 ‑ 1/0
380‑05051 Single Oval‑Point Screw 2/0 ‑ 1/0
380‑05053 Single Oval‑Point Screw 2/0 ‑ 1/0
380‑05056 Single Oval‑Point Screw 2/0 ‑ 1/0

816 ORSNASCO.COM © 2016
