Lockout Tagout - Electrical Lockout

Button Lockout Button Lockout
Manufactured from Glass Resin Polycarbonate, this Lockout This Lockout unit ts around the
unit ts around the stem of a button which can then be stem of a button which can then
locked out using a standard padlock. be locked out using up to two
standard padlocks.
This unit can be xed either permanently or temporarily. Manufactured from Glass Resin
To t permanently, use the circular section around the stem Polycarbonate.
of the button and shut the cover in place when needed.
Hole diameter of 22 - 30mm.
To t temporarily, use the semi-circular section
to sit round the stem prior to tting Size Code
the cover and remove when nished. See Below LOK187

Size Code
See Below LOK195

Step 1 Step 2 Step 3

Step 1 Step 2 Step 3 Step 4

B

G F A

C
E D

Dimensions Dimensions
(A) (B) (C) (D) (E) (F) (G) (H) (I) (A) (B) (C) (D) (E) (F) (G)
60mm 46mm 49mm 55mm 52mm 35mm 22mm 40mm 29mm 50mm 8mm 18mm 35mm 50mm 33mm 22mm

Electrical Labels

Our Electrical Safety Labels are
durable and convenient. They are
available in a range of sizes, packs

and roll quantities.

Find the full range of Electrical
Labels on page 138.
