Page 10 - PANEL CUBB SDD

1 2 3 4 5 6 7 8

A
A

CABLE POWER 48 VDC
B
CABLE 3 CORE B
POWER -48VDC

X3.3 - (Hitam) XDI2.3 - (Hitam)

X3.1 - (Merah) XDI2.1 - (Merah) GROUND

C Ground - (Biru) Ground - (Biru)
C

CABLE POWER 220 VAC

D
CABLE 3 CORE D
IN 220V ACL

CB1.2 - (Hitam) Source Pln - (Hitam)

CB1.4 - (Biru) Source Pln - (Biru) GROUND

Ground - (Merah) Ground - (Merah)
E
E

00 Issued For Approval 02/02/22 ARRY Prepared. ARRY Project name Customer Based on Ref. designation = Lang. Scale.
F 01 Issued For Approval 08/02/22 ARRY Checked SEPTA SLD CONECTION PT. PLN PERSERO Document kind External doc.id
CABLE
02 Issued For Approval 25/02/22 ARRY Approved SEPTA Resp. PT. ARHADI FAJAR Tittle. SHEET DIAGRAM Document Id. DCC Page. Cont. Page F
Ref Description Date Name Date Prep.29/02/22 Work order id. REVP01 PERKASA PANEL CUB ID-PAFP0O2 &ELH 01 01
1 2 3 4 5 6 7 8
