BIG LIGHT 2017 ∙ OUTDOOR WALL LIGHTS 181

ONI ONI 2
Wall Pack, LED Wall Pack, LED
• Available in 42W 4024 lumens and 62W 5234 • Available in 94W 7152 lumens and 155W
lumens versions 11,982 lumens versions
• Sturdy die-cast aluminum housing • Sturdy die-cast aluminum housing
• UV stabilized powder coated finish • UV stabilized powder coated finish
Lamp details Lamp details
LED 1x 3000K CRI>80 LED 1x 3000K CRI>80

Product details Product details
120-277V 120-277V
Material: Die-cast Aluminum Material: Die-cast Aluminum
W: 7.5 in. H: 8 in. D: 2.79 in. W: 12.8 in. H: 14 in. D: 5 in.
dimmable: C, Triac dimmable: C, Triac

3.63 50000 12.4 50000

Series available in other variants Series available in other variants
Product family Oni see page 014–019. Product family Oni see page 014–019.
2.79” 5.0”

8.0” 14.0”

7.5” 12.75”
Rec. accessory Item No.
Rec. accessory Item No. Slipfitter and J-Box ONI 2 707606U
Trunnion and J-Box ONI 707607U Slipfitter and J-Box ONI 2, Small 707585U
Slipfitter and J-Box ONI 707608U Trunnion and J-Box ONI 2 707595U

Variant Item No. Variant Item No.
4024lm, 42W 7152lm, 94W
Bronze 707545U Bronze 707565U
5234lm, 62W 11982lm, 155W
Bronze, 707555U Bronze 707575U
