KEGIATAN
BELAJAR 1

AwardBIOS Setup Utility
Main Advanced Power Boot Exit

Item Specific Help
Power Manajement [User Defined]

Video Off Option [Suspend -> Off]
Video Off Method [DPMS OFF] <Enter> to select the
HDD Power Down [Disabled] power saving mode.
ACPI Suspend To RAM [Disabled] You can select [User
Defined] to go to the
Suspend Mode [Disabled] suspend mode entry
PWR Button < 4 Secs [Soft Off] below.

► Power Up Control
► Hardware Monitor

F1 Help Select Item -/+ Change Values Enter F5 Setup Defaults F10
ESC Exit Select Menu Select Sub-Menu Save and Exit

11) Selanjutnya buka menu [Boot]. Nah, untuk memudahkan

penginstalan sistem operasi yang akan dilakukan setelah

ini, ubahlah pola boot dari PC. Set CD ROM sebagai boot

device pertama, kemudian hardisk sebagai boot device ke

dua dan floopy sebagai boot device ketiga, dengan

menggunakan tombol [+] atau [-]. Gunanya, agar tiap kali

booting, komputer mencari adanya sistem operasi di CD-

ROM dulu, baru kemudian hard disk, dan floopy.

AwardBIOS Setup Utility Main
Advanced Power Boot Exit
Item Specific Help
1. ATAPI CD-ROM [CREATIVE IR CD5222E-]
2. IDE Hard Drive [ST320011A]
3. Removable Device [Legacy Floppy] Boot Sequence:
4. Other Boot Device [INT18 Device Network] <Enter> to select the
Plug & Play O/S [Yes] Reset device.
Configuration Data [No]
Boot Virus Detection [Disabled] Quick TO select the boot
sequence, use the up or down
Power On Self Test [Enabled] Boot Up Floppy
Seek [Enabled] Full arrow. Press <+> to move the
Screen Logo [Disabled] device up the list, or <->
Interrupt Mode [APIC] to move it down the list.

F1 Help Select Item -/+ Change Values ESC Exit F5 Setup Defaults F10
Select Menu Enter Select Sub-Menu Save and Exit
12) Masukkan CD instalasi Windows XP ke CD-ROM drive.

Setelah itu, pilih menu [Exit] [Exit Saving Changes] untuk

keluar dari BIOS dan menyimpan pengaturan yang Anda

buat barusan. Selanjutnya komputer akan restart. Jika

24
