CUSTOM FLEXIBLE CONNECTOR SELECTION FORM Information Required at Factory

FLEXIBLE BRAID: Amp Rating:
Type of Braid (Flat, Rope): Plating Required (Tin, Silver, None):
Braid Stranding and Gauge: Number of Holes Per End:
Total Circular Mils.: Hole Pattern:
Connector Width: Hole Diameters/Slotted Hole Dimensions:
Connector Thickness: Hole Spacing:
Connector Shape: Insulation Required:
(Flat, U shape, Angle, Twist, etc.) Special Design Considerations:
Quantity:
Overall Connector Length:
Ferrule Length (Each end): Amp Rating:
Plating Required (Tin, Silver, None):
LAMINATED SHUNTS: Number of Holes Per End:
Lamination (Number of laminates): Hole Pattern:
Copper Strip Thickness: Hole Diameters:
Brazing Material if needed: Hole Spacing:
Connector Width: Special Design Considerations:
Connector Thickness: Quantity:
Connector Shape:
(Flat, U shape, Angle, etc.)
Overall Connector Length:
Pad Length (Each end):

CUSTOMER PROFILE:

Company Name:

Address:

City: State: Country: Zip:
Fax:
Phone:

Buyer’s Name/Title: Fax or Email to:
Attn: Customer Service
Email:
Fax: 814.734.4946
Delivery Date Required: info@penn-union.com
