ALUMINUM COMPRESSION LUGS

    TYPE BLUA-D-NT ALUMINUM PENN-CRIMPS®                                                                                                      NEW PRODUCT

    Aluminum Compression Lug - Two Hole - Narrow Tongue

    • Manufactured from seamless aluminum tubing                                                                              AL9CU

    • Tin-plated and factory prefilled with oxide inhibitor compound

    • Beveled entry for easy cable insertion

    • Narrow Tongue width designed for limited space applications

    • Connectors are marked with catalog number, wire size, die index
    	 and crimp locations

    • Color coding conforms to industry requirements insuring proper
    	 die selection and providing for a faster installation

    • Connectors are suitable for voltages up to 35KV

    • Connectors are UL Listed and CSA Certified with Penn-Union,
    	 Burndy, T&B, Huskie and Greenlee tooling

    • End caps provided to prevent foreign materials from
    	 entering and contaminating the connector prior to usage

    BLUA-D-NT DIMENSIONS & INDEX REFERENCE

                   ALUMINUM                    FIGURE DIMENSIONS (IN.)                                                               INSTALLATION TOOLING
                    & COPPER                 TONGUE TONGUE TONGUE BARREL OVERALL
                   CONDUCTOR  STUD   STUD    WIDTH LENGTH THICKNESS LENGTH LENGTH  COLOR                                      PENN-UNION DIELESS BURNDY DIE T&B DIE     WIRE
      CATALOG NO.             HOLE    HOLE                                         CODE                                              MECHANICAL TOOLS INDEX NO. INDEX   STRIP
                       SIZE   SIZE  SPACING    “W” “C” “T” “B” “L”                                                                            /TOOL        NO.         LENGTH
    BLUA-035D1-NT  350 kcmil
    BLUA-035D-NT   400 kcmil  3/8”   1.00    1.25 2.06 0.46 1.59 4.44                                                                TDM-500               299 87 1-3/4”
    BLUA-040D1-NT  500 kcmil  1/2”   1.75                                                        Brown
    BLUA-040D2-NT  600 kcmil  3/8”   1.00
    BLUA-050D1-NT  750 kcmil  1/2”   1.75    1.25 2.94 0.46 1.59 5.31
    BLUA-050D2-NT             3/8”   1.00
    BLUA-060D1-NT     1000    1/2”   1.75    1.25 2.06 0.55 1.81 4.56              Green                                             TDM-500               472 94      2”
    BLUA-060D2-NT     kcmil   3/8”   1.00    1.25 3.13 0.55 1.81 5.63
    BLUA-075D1-NT             1/2”   1.75
    BLUA-075D-NT              1/2”   1.75    1.32 2.06 0.54 1.88 4.88              Pink                                              TDM-500               300 106 2-1/16”
                              5/8”   1.75    1.32 3.13 0.54 1.88 5.94
    BLUA-100D2-NT
                              1/2”   1.75    1.30 2.06 0.79 2.00 5.19              Black                                                                   473 115 2-3/16”
                                             1.30 3.13 0.79 2.00 6.25

                                             1.49 3.13 0.63 2.25 6.31              Red                                                                     301 130 2-7/16”
                                             1.49 3.22 0.63 2.25 6.41                                                                                      302 150 2-3/4”

                                             1.61 3.13 1.02 2.56 7.34 Brown

    • Connectors from 8 AWG - 1000 kcmil are UL Listed per UL486A-B and CSA Certified per C22.2 No.65 for POWER applications
