Page 53 - 2020 October Lighting Catalog
P. 53
Accessories / ballasts
Vandal/Environmental Shield Guard
Polycarbonate
Cat. For Use With Size Case Each
No. (Ht x W x D) Qty
73090 Exit Lights & Cast Aluminum Exit Lights 9” X 13.25” X 2.50” 16
73091 Emergency Lights 7” x 8.5” x 19.5” 3
73090 73091
Wire Guards
Cat. For Use With Size Case Each
No. (Ht x W x D) Qty
Emergency Lights, Exit Lights
73095 13.5” X 15” X 6” 10
& Cast Aluminum Exit Lights
73096 Combo Exit/Emergency Lights 13.5” X 30” X 6” 5
LED Exit Sign Retrofit Kits
Hard Wire
Cat. No. Description Box Qty Each
73080 Hard Wire Unit Red LED 1
73081 Hard Wire Unit Green LED 1
LED Exit Sign Retrofit Kits
Screw-In
Cat. No. Description Box Qty Each
73082 Screw-in Unit Red LED 1
73084 Screw-in Unit Green LED 1
Fluorescent Emergency Lighting Ballasts
Fig 1 Fig 2 Fig 3 Fig 4
Cat. Fig Lumens Lamp Lamp No. of Wattage Input volts Length Width Height Case EacH
No. Type Length Lamps Wattage Qty
72900 1 500 T8-T12 2’ - 4’ 1 17-40 2.5 120/277V 9.4” 2.4” 1.5” 6
72901 2 300-650 2 Pin CFL N/A 1 10-26 3.5 120/277V 9.4” 2.4” 1.5” 6
72902 2 300-650 4 Pin CFL N/A 1 or 2 13-42 3.5 120/277V 9.4” 2.4” 1.5” 6
72903 1 700 T8-T12 2’ - 8’ 1 or 2 17-110 3.5 120/277V 9.4” 2.4” 1.5” 6
72904 1 1400 T8-T12 2’ - 8’ 1 or 2 17-215 4.0 120/277V 13.3” 2.4” 1.5” 6
72905 3 1450-3000 T8-T12 2’ - 8’ 1 or 2 17-215 8.0 120/277V 16.26” 5.5” 1.75” 2
Cat. Fig Lumens Lamp Lamp No. of Wattage 1 Wattage Input volts Length Width Height Case Each
No. Type Length Lamps Lamp 2 Lamp Wattage Qty
72910 4 500 T5-T8 2’ - 4’ 1 28 N/A 2.5 120/277V 10” 2” 1” 6
72913 4 700 T5-T8 2’ - 4’ 1 or 2 14-54 14-39 3.32/3.78 120/277V 13.8” 2” 1” 6
72914 4 1400 T5-T8 2’ - 4’ 1 or 2 14-54 14-39 3.25/3.78 120/277V 14.2” 2” 1” 6
Please review online specification sheets. Pictures and certifications may not be 100% representative of the product listed.
To view details of our DLC qualified products, please consult the DLC Qualified Products List at www.designlights.org/qpl
FOR MORE INFO SEE THE 2019 LIGHTING Catalog and or visit morrisproducts.com 51
