INDUSTRIAL/

INSTITUTIONAL SERIES

THERMOPLASTIC RUBBER (TPR)/ MEDIUM PLATE
LIGHT/MEDIUM DUTY

Series 26/27 • Swivel P2 Plate Casters • TPR
Tread Width Caster Finish
1 1/4" Zinc Plated Steel
Load
Wheel
Swivel Caster Diameter Overall Capacity Features
Height
Axle Hub Width
3/8” 1 5/8" Z26P234NEKI 4 1/4” 180 LBS Swivel
Z26P234NEKIB 4 1/4” 180 LBS Side Brake
Bearing Durometer Z26P234NEKIL 180 LBS Total Lock Brake
Dual Precision A70 3” 4 1/4”
Z26P234NEKIR 4 1/4” 180 LBS Directional Brake
Attachment Type Operating Temp Z26P234NEKIT 4 1/4” 180 LBS Top Lock Brake
Plate -30°F TO 140°F Z26P274NEKI 4 11/16” 225 LBS Swivel
Z26P274NEKIB 4 11/16” 225 LBS Side Brake
Attachment Size Wheel Type
3 1/8” x 4 1/8” TPR Z26P274NEKIL 3 1/2” 4 11/16” 225 LBS Total Lock Brake
Z26P274NEKIR 4 11/16” 225 LBS Directional Brake
Wheel Color
Gray/Black Z26P274NEKIT 4 11/16” 225 LBS Top Lock Brake
Z26P244NEKI 5 1/8” 250 LBS Swivel
FEATURES Z26P244NEKIB 5 1/8” 250 LBS Side Brake
Z26P244NEKIL 4” 5 1/8” 250 LBS Total Lock Brake
Z26P244NEKIR 5 1/8” 250 LBS Directional Brake
Resistant to Chemicals brake options for both rigid
Excellent for Wet and swivel models. Z26P244NEKIT 5 1/8” 250 LBS Top Lock Brake
Environments Z26P254NEKI 6 3/16” 300 LBS Swivel
Designed to work together Z26P254NEKIB 6 3/16” 300 LBS Side Brake
Wide range of wheel and
Z26P254NEKIL 5” 6 3/16” 300 LBS Total Lock Brake
Z26P254NEKIR 6 3/16” 300 LBS Directional Brake
APPLICATIONS Z26P254NEKIT 6 3/16” 300 LBS Top Lock Brake

Z26P264NEKI 7 1/4” 325 LBS Swivel
Institutional Retail Environment Z26P264NEKIL 7 1/4” 325 LBS Total Lock Brake
Commercial Medical 6”
Z26P264NEKIR 7 1/4” 325 LBS Directional Brake
Light Industrial Hospitality 325 LBS Top Lock Brake
Pharmaceutical/ Janitorial Z26P264NEKIT 7 1/4”
Laboratory Z26P284NEKI 9 1/4” 350 LBS Swivel
Z26P284NEKIL 9 1/4” 350 LBS Total Lock Brake
8”
TECHNICAL Z26P284NEKIR 9 1/4” 350 LBS Directional Brake
Z26P284NEKIT 9 1/4” 350 LBS Top Lock Brake
Series 26/27 • Rigid P2 Plate Casters • TPR

Wheel Overall Load
Rigid Caster Features
Diameter Height Capacity
Z27P234NEKI 3” 4 1/4” 180 LBS Rigid
Z27P274NEKI 3 1/2” 4 11/16” 225 LBS Rigid
Z27P244NEKI 4” 5 1/8” 250 LBS Rigid
Z27P254NEKI 5” 6 3/16” 300 LBS Rigid
Z27P264NEKH 6” 7 1/4” 325 LBS Rigid
Z27P284NEKH 8” 9 1/4” 350 LBS Gray/Black
