INDUSTRIAL/

INSTITUTIONAL SERIES

THERMOPLASTIC RUBBER (TPR)/ LARGE PLATE
LIGHT/MEDIUM DUTY

Load capacity up to 400 LBS

Series 26/27 • Swivel P3 Plate Casters • TPR
Tread Width Hub Width
1 1/4" 1 5/8" Swivel Caster Wheel Overall Load Attachment Size Features
Diameter Height Capacity
Axle Durometer Z26P334NEKI 4 1/4” 180 LBS 4 x 4 1/2” Swivel
3/8” A70
Z26P334NEKIB 4 1/4” 180 LBS 4 x 4 1/2” Side Brake
Bearing Operating Temp Z26P334NEKIL 3" 4 1/4” 180 LBS 4 x 4 1/2” Total Lock Brake
Dual Precision -30°F TO 140°F Z26P334NEKIR 4 1/4” 180 LBS 4 x 4 1/2” Directional Brake
Z26P334NEKIT 4 1/4” 180 LBS 4 x 4 1/2” Top Lock Brake
Attachment Type Wheel Type
Plate TPR Z26P374NEKI 4 11/16” 225 LBS 4 x 4 1/2” Swivel
Z26P374NEKIB 4 11/16” 225 LBS 4 x 4 1/2” Side Brake
Caster Finish Wheel Color Z26P374NEKIL 3 1/2” 4 11/15” 225 LBS 4 x 4 1/2” Total Lock Brake
Zinc Plated Steel Gray/Black Z26P374NEKIR 4 11/16” 225 LBS 4 x 4 1/2” Directional Brake
Z26P374NEKIT 4 11/16” 225 LBS 4 x 4 1/2” Top Lock Brake
Z26P344NEKI 5 1/8” 250 LBS 4 x 4 1/2” Swivel
FEATURES Z26P344NEKIB 5 1/8” 250 LBS 4 x 4 1/2” Side Brake

Z26P344NEKIL 4" 5 1/8” 250 LBS 4 x 4 1/2” Total Lock Brake
Resistant to Chemicals brake options for both rigid Z26P344NEKIR 5 1/8” 250 LBS 4 x 4 1/2” Directional Brake
Excellent for Wet and swivel models. Z26P344NEKIT 250 LBS Top Lock Brake
Environments 5 1/8” 4 x 4 1/2”
Designed to work together Z26P354NEKI 6 3/16” 300 LBS 4 x 4 1/2” Swivel
Wide range of wheel and Z26P354NEKIB 6 3/16” 300 LBS 4 x 4 1/2” Side Brake
Z26P354NEKIL 5" 6 3/16” 300 LBS 4 x 4 1/2” Total Lock Brake

APPLICATIONS Z26P354NEKIR 6 3/16” 300 LBS 4 x 4 1/2” Directional Brake
Z26P354NEKIT 6 3/16” 300 LBS 4 x 4 1/2” Top Lock Brake
Z26P364NEKI 7 1/4” 325 LBS 4 x 4 1/2” Swivel
Institutional Retail Environment
Z26P364NEKIL 7 1/4” 325 LBS 4 x 4 1/2” Total Lock Brake
Commercial Medical 6"
Light Industrial Hospitality Z26P364NEKIR 7 1/4” 325 LBS 4 x 4 1/2” Directional Brake
Pharmaceutical/ Janitorial Z26P364NEKIT 7 1/4” 325 LBS 4 x 4 1/2” Top Lock Brake
Laboratory Z26P384NEKI 9 1/4” 325 LBS 2 3/8” x 3 5/8” Swivel

Z26P384NEKIL 9 1/4” 325 LBS 2 3/8” x 3 5/8” Total Lock Brake
8"
TECHNICAL Z26P384NEKIR 9 1/4” 325 LBS 2 3/8” x 3 5/8” Directional Brake
Z26P384NEKIT 9 1/4” 325 LBS 2 3/8” x 3 5/8” Top Lock Brake
Series 26/27 • Rigid P3 Plate Casters • TPR

Rigid Caster Wheel Overall Load Attachment Size Features
Diameter Height Capacity
Z26P334NEKI 3" 4 1/4” 180 LBS 4 x 4 1/2” Rigid
Z26P364NEKIT 3 1/2” 4 5/8” 225 LBS 4 x 4 1/2” Rigid
Z26P384NEKI 4" 5 1/4” 250 LBS 4 x 4 1/2” Rigid
Z26P384NEKIL 5" 6 1/4” 300 LBS 4 x 4 1/2” Rigid
Z26P384NEKIR 6" 7 1/4” 325 LBS 4 x 4 1/2” Rigid
Z26P384NEKIT 8" 9 1/4” 350 LBS 4 x 4 1/2” Gray/Black

43
