Page 124 - 2016-2017 Racecar Engineering Late Model Muscle Car Parts and Accessories Catalog

GM LS Engine Ignition Components
One of the hottest engines around is undoubtedly GM's Gen III, most often referred to as the LS1,
LS6 and LS7. Check out these fine MSD components that will make the LS Series engine even hotter.

6LS And 6LS-2 1997-Up Corvette
Ignition Controllers LS-Series Street Fire Wires MSD5572
The 6LS and 6LS-2 ignition control- Street Fire spark plug wires have a low resistance
lers can now be installed on EFI or car- conductor wrapped in a sleek and durable black
buretor equipped engines. The controllers map a timing advance curve sleeve. The terminals are covered in black boots to
with MSD's easy-to-use Pro-Data+ software. Other programmable protect the conductor from engine heat.
features include a two-step retard in case nitrous is in the mix.
The 6LS unit is designed for LS1/LS6 type engines with a 24-tooth
wheel, which can be identified by its black harness connector. EFI Harnesses
The 6LS-2 unit is designed for the LS2/LS7 and its 58-tooth wheel, Easily connect the 6LS or 6LS-2 to a factory
which has a gray harness connector. EFI system to take advantage of timing
Part No. Description adjustments and settings.
MSD6010 ........6LS Controller For LS1/LS6 Engines (24-Tooth Crank Trigger) Part No. Description
MSD6012 ........6LS-2 Controller For LS2/LS7 Engines (58-Tooth Crank Trigger) MSD8886 ........For 6LS To EFI Harness, LS1/LS6 Engines
MSD88862 ......For 6LS-2 To EFI Harness, LS2/LS7 Engines

Atomic AirForce LS-Series Intake Manifold
This polymer manufactured manifold maximizes airflow and improves distribution thanks to its uniquely designed runners
that maximize plenum volume. The result is noticable horsepower gains for stock and modified LS powerplants. The Atomic
AirForce intake accepts an OEM or a 103mm throttle body as well as factory or aftermarket fuel rails. Mounting gaskets and
hardware included.
Part No. Description
MSD2700 .......2014-15 Corvette LT1
MSD2701 .......2006-13 Corvette LS7
MSD2702* .....1997-04 LS1/LS6, 2005-07 Corvette, LS2
* Factory Throttle Body Requires MSD2709 Adaptor. Must use LS2 or aftermarket fuel rails)

Iridium IX Spark Plugs
Spark plugs are engineered specifically for performance enthusiasts and deliver improved throttle response, fuel effi-
ciency and durability. A fine iridium tip, which has an extremely high melting point, provides an extended life and consistent,
extreme ignitability.
Part No. Application
NGKTR6IX ......... 2010-13 Corvette 6.2L V8 Supercharged, Iridium
NGKTR5 ........... 2010-13 Corvette 6.2L V8 Non S/C, V-Power
NGKTR5IX ......... 2010-13 Corvette 6.2L V8 Non S/C, Iridium
NGKTR5 ........... 2008-09 Corvette 6.2L V8, V-Power
NGKTR5IX ......... 2008-09 Corvette 6.2L V8, Iridium
NGKTR6 ........... 2006-13 Corvette 7.0L V8, V-Power
NGKTR6IX ......... 2006-13 Corvette 7.0L V8, Iridium
NGKTR5 ........... 2005-07 Corvette 6.0L V8, V-Power
NGKTR5IX ......... 2005-07 Corvette 6.0L V8, Iridium
NGKTR5 ........... 1997-04 Corvette 5.7L V8, V-Power
NGKTR5IX ......... 1997-04 Corvette 5.7L V8, Iridium
