Page 126 - 2016-2017 Racecar Engineering Late Model Muscle Car Parts and Accessories Catalog

Pre-Assembled, Direct Bolt-On Brake Hose Kits
Direct bolt-on brake hoses bring the ultimate in braking performance. They improve your braking perfor-
mance for competition or every-day driving. Replacing the O.E. rubber hoses with Russell brake hoses reduces
brake hose expansion for more consistent braking. Featuring stainless steel braided hose with zinc-plated fittings, these brake hoses th b k h
are factory assembled for convenient installation. They meet the guidelines of the U.S. Dept. of Transportation MVSS-571.106 requirements.
Brake Hose Speed Bleeders
Year And Model Part No. Front Rear Hoses Per Kit Front Rear
1997-04 Corvette C5 (Including Z06) RUS692190 Disc Disc 4 RUS639630 RUS639630
2005-12 Corvette C6 RUS692350 Disc Disc 4 RUS639560 RUS639560
2006-12 Corvette Z06 RUS692200 Disc Disc 4 RUS639560 RUS639560

True Balance Billet Flywheels
Ram flywheels are ready to bolt in – out of the box.
HDX And Powergrip Each unit is CNC machined, surface ground parallel to
the crank flange, and precision balanced.
Clutch Sets Make Ring Gear Balance Steel Aluminum
Ram HDX clutch sets feature increased clamp Small Block LS1 168-Tooth Internal RAM1550 RAM2550
loads and a high performance street organic disc. Discs are built with
the exclusive 8-spring hub and poly coil springs for excellent strength Force 9.5 and 10.5 Dual Disc Clutch Systems
and durability. HDX sets provide the smoothest engagement for street Force 9.5 and 10.5 clutches combine the benefits of
driven cars. For performance street/strip cars, Powergrip sets include smooth driveability and easy pedal effort with extreme
the same increased clampload pressure plates with a 900/300 series holding power. The strapped floater plate eliminates
friction material for a balance between driveability and holding power noise at idle. Force 9.5 are suited for applications with
up to 550 hp at the wheels. up to 750 horsepower, while the 10.5 is for use in
Part No. Description vehicles with up to 1,000 horsepower. Designed as a
RAM88931HDX ... 2005-12 V8, HDX, 11.0" x 1-1/8", 26-Spline bolt-in for late model vehicles, kits are sold complete
1
RAM98931 1 ........ 2005-12 V8, Powergrip, 11.0" x 1-1/8", 26-Spline with a billet aluminum flywheel.
RAM98931HD 1 ..... 2005-12 V8, HD, 11.0" x 1-1/8", 26-Spline Force 9.5 Force 10
RAM88931HDX ..... 1997-04 Corvette LS 1998-02 HDX, 11.0" x 1-1/8", 26-Spline Applications Part No. Part No.
RAM88931 .......... 1997-04 Corvette Powergrip 11.0" x 1-1/8", 26-Spline 1997-12 GM LS, 1-1/8”-26 Spline, 168T Flywheel,
RAM98931HD....... 1997-04 Corvette HD 11.0" x 1-1/8", 26-Spline “O” Balance RAM75-2100 RAM80-2100
1 Requires Ram Flywheel
Street Hydraulic Release Bearings Hydraulic System Adjuster RAM78300
For applications where the standard release mechanism Allows adjusting clutch pedal position
may not fit. Bearings feature .700" travel, and work with in virtually any vehicle using an internal
up to a 3/4" master cylinder. T56 kits include all hard- hydraulic slave cylinder. Unit plumbs
ware to adapt to the OEM master cylinder. inline with the feed line from the slave
Part No. Description cylinder and is compatible with all
RAM78165 .......... 1997-04 Corvette factory or aftermarket hydraulic clutch
RAM78170 .......... 2005-12 Corvette release bearings.

Livewire TS+ Programmer And Monitor SCT5416P
Pre-loaded with dyno-proven tune files, the Livewire TS+ utilizes a
color 4" touch screen display that provides the ability to store up to
10 custom tunes, read and clear DTC codes, perform high speed data
X4 Power Flash Programmer logging/monitoring, while also utilizing built-in WiFi for easy updates, a
SCT7416 performance calculator and user-selectable graphics and gauge layouts.
Fully compatible with all 1999-13 Corvette 5.7/6.0L/6.2L/7.0L.
Easy to use programmer delivers
increased horsepower and torque iTSX/TSX For Android And Apple Wireless Programmer SCT4416
using pre-loaded, dyno-proven
tunes, specifically calibrated for Designed for use with Apple or Android devices, the iTSX/TSX
1999-13 Corvette 5.7/6.2L/6.2L/7.0L. Programmer delivers completely wireless vehicle tuning to all 1999-13 Corvette
features a full color, backlit LED display that also allows 5.7/6.0L/6.2L/7.0L. Fully loaded with dyno-proven files, program-
high speed data logging/monitoring, reading/clearing DTC mer additionally includes on-screen virtual gauges and the ability to
codes, storage of up to 10 custom tunes and easy restora- built-in performance tests, read and clear DTC codes, and back-up
tion back to stock, if desired. the factory tune with easy restoration back to stock.

125
125
125
2016-17 CORVETTE PRODUCTS 125
