Page 142 - 2016-2017 Racecar Engineering Late Model Muscle Car Parts and Accessories Catalog

Street Fire Wires
Street Fire spark plug wires have a low resistance conductor wrapped in a sleek and durable black sleeve. The terminals are
covered in black boots to protect the conductor from engine heat.
Part No. Description
MSD5572 ......... 1998-02 Firebird LS-Series
MSD5575 ......... 1993-96 Firebird LT1
Pro-Billet LT 1 Distributor
Machined aluminum housing designed to replace the OEM LT1 OptiSpark distributor. Easily adjust timing up to +/-6 degrees
with large ball bearings that stabalize timing through 10,000 rpm. Supplied with heavy duty LT 1 cap, rotor, and all components
needed for installation.
Part No. Application Advance Ignition System
MSD8381 GM 1992-94 LT-1 (Early) * Adjustable OEM
MSD83811 GM 1994-96 LT-1 (Late) ** Adjustable OEM MSD8381
* Spline Drive
* * Pin Drive
1993-02 Firebird Ignition Components
MSD offers a wide variety of ignition components for popular 1993-02 Firebirds.
Part No. Description Part No. Description
9993-97 Firebird LT1 V8 MSD8226 1998-02 Firebird LS1 V8
MSD8226 ........ 1993-95, Replacement Coil - Dual Connector MSD6010 ........ 1998-02, 6LS Ignition Controller MSD6010
MSD8231 ........ 1996-97, Replacement Coil - SingleConnector MSD8215 ........ 1998-02, Coil Brackets For OEM Or MSD Coils
MSD8381 ........ 1993-94, Pro-Billet Distributor - Early Model Spline Driven MSD8886 ........ 1998-02, EFI Wire Harness To Install MSD6010
MSD83811 ...... 1994-97, Pro-Billet Distributor - Late Model Pin Driven MSD32813 ...... 1998-02, Direct Fit Spark Plug Wire Set - Black
MSD8481 ........ 1993-94, Replacement Distributor Cap/Rotor Kit - Early Model MSD32819 ...... 1998-02, Direct Fit Spark Plug Wire Set - Red
MSD84811 ...... 1994-97, Replacement Distributor Cap/Rotor Kit - Late Model MSD82858 ...... 1998-02, Direct Fit Coils - Set of 8 (VIN #G)
MSD8876 ........ 1993-95, Wiring Harness To Install MSD6201/6425 MSD88867 ...... 1998-02, Direct Fit Power Upgrade Coil Wire Harness
MSD8877 ........ 1996-97, Wiring Harness To Install MSD6201/6425
MSD32143 ...... 1993-97, Direct Fit Spark Plug Wire Set - Black
MSD32149 ...... 1993-97, Direct Fit Spark Plug Wire Set - Red
6LS And 6LS-2 Ignition Controllers
The 6LS and 6LS-2 ignition controllers can now be installed on EFI or carburetor equipped engines. The controllers
map a timing advance curve with MSD's easy-to-use Pro-Data+ software. Other programmable features include a two-
step retard in case nitrous is in the mix.
The 6LS unit is designed for LS1/LS6 type engines with a 24-tooth wheel, which can be identified by its black har-
ness connector.
The 6LS-2 unit is designed for the LS2/LS7 and its 58-tooth wheel, which has a gray harness connector.
Part No. Description
MSD6010 ........ 6LS Controller For LS1/LS6 Engines (24-Tooth Crank Trigger)
MSD6012 ........ 6LS-2 Controller For LS2/LS7 Engines (58-Tooth Crank Trigger)
EFI Harnesses
Easily connect the 6LS or 6LS-2 to a factory EFI system to take advantage of timing adjustments and settings.
Part No. Description
MSD8886 .........For 6LS To EFI Harness, LS1/LS6 Engines
MSD88862 .......For 6LS-2 To EFI Harness, LS2/LS7 Engines
Atomic AirForce LS-Series Intake Manifold
This polymer manufactured manifold maximizes airflow and improves distribution thanks to its
uniquely designed runners that maximize plenum volume. The result is noticable horsepower gains for
stock and modified LS powerplants. The Atomic AirForce intake accepts an OEM or a 103mm throttle
body as well as factory or aftermarket fuel rails. Mounting gaskets and hardware included.
Part No. Description
MSD2702* .......... 2005-06 Pontiac GTO LS2, 2004 Pontiac GTO LS1/LS6, 1998-02 Firebird
* Factory Throttle Body Requires MSD2709 Adaptor. Must use LS2 or aftermarket fuel rails)

2016-17 PONTIAC PRODUCTS 141
