Page 46 - 2016-2017 Racecar Engineering Late Model Muscle Car Parts and Accessories Catalog

H-Pipes
Part No. Description
PYPHFM23 ......2005-10 Mustang 4.6L, V8 Off Road H-Pipe For HDR55S Headers
Off-Road H- And X-Pipes PYPHFM24 ......2011-14 Mustang 5.0L, 3" Off Road H-Pipe
PYPHFM53 ......1998-04 Mustang 4.6L, V8 Off Road H-Pipe For HDR53S Headers
PYPHFM76 ......2011-14 Mustang 5.0L, V8 Catted H-Pipe For HDR76S Headers
X-Pipes
Part No. Description
PYPHFM23 PYPXFM16 ......1994-04 Mustang 4.6L V8, Off Road X-Pipe
PYPXFM19 ......1998-04 Mustang 3.8L V6, Off Road X-Pipe
PYPXFM23 ......2005-10 Mustang 4.6L V8, Off Road X-Pipe
PYPXFM16 PYPXFM24 ......2011-14 Mustang 5.0L V8, Off Road X-Pipe
PYPXFM36 ......1999-04 Mustang 4.6L V8, Catted X-Pipe
PYPXFM43 ......2005-10 Mustang 4.6L V8, AFT Cat X-Pipe
PYPXFM45 ......2011-14 Mustang 5.0L V8, AFT Cat X-Pipe
PYPXFM75 ......2011-14 Mustang 5.0L V8, Off Road X-Pipe For HDR76S Headers
Direct fit with bolt-on connections for ease of installation, H- and X- PYPXFM76 ......2011-14 Mustang 5.0L V8, Catted X-Pipe For HDR76S Headers
pipes are constructed from mandrel-bent tubing for maximum exhaust
flow and improved acceleration. Durable, 409 stainless, 16-gauge
construction provides extended durability and corrosion resistance.

Struts
Aluminum-bodied, mono-tube struts are three pounds lighter
and compatible with stock or aftermarket K-members. Exter-
nally adjustable valves are accessible from under the hood.
Sold individually.
Tubular Control Arms Part No. Description
QA1HS603S ......... 1994-04 Mustang, 2" Lowered, 5.0L
QA1’s tubular steel control arms reduce unsprung weight and improve QA1HS603S ......... 1994-04 Mustang, 4.6/5.4L
handling. Eco Street arms have compressed rubber bushings for control QA1HS605S* ....... 2005-14 Mustang, With Sway Bar Bracket
and smooth ride. Race-proven Pro-Comp arms have heat treated, XM * Requires QA1CC105MU Camber Plate.
Heim ends with PTFE/Kevlar linings for performance and durability.
Spacers for forward and rearward wheel base adjustment are included.
Part No. Description Caster/Camber Plates
Eco Street Tubular Control Arms
QA1MU2ESA ........ 1994-04 Mustang, 4.6/5.0L QA1’s Caster/Camber plates incorporate an
Pro-Comp Tubular Control Arms asymmetrical bearing that provides improved
QA1MU2TCA ........ 1994-04 Mustang, 4.6/5.0L load distribution and reduced wear, eliminating
the road noise and poor handling associated
Note: Tubular Control Arms require QA1 coil-over struts and caster/ with the OEM design.
camber plates.
Part No. Description
QA1CC104MU....... 1994-04 Ford Mustang 4.6/5.0L
Tubular K-Members QA1CC105MU....... 2005-14 Ford Mustang
Up to 28 pounds
lighter than the stock K-
Member. Unit improves 1994-04 Mustang 4.6/5.0L Including
bump steer, anti-dive Cobra Bump Steer Kit QA1BAX104
and Ackerman char-
acteristics. Provides Correct bump steer caused by changes in toe-
additional header and oil in during suspension travel. "X" series rod ends
pan clearance. with jam nuts, anodized aluminum adjusting
sleeves with jam nuts, special spindle studs with
Part No. Description
QA1MU1TK .......... 1996-04 Mustang 4.6L washer and lock nut, and bump steer spacer
QA1MU2TK .......... 1994-95 Mustang 5.0L assortment are included.
K-Member Brace QA152105 Sway Bar Kit
Engineered for 1994-04 Ford QA152889
Mustang, heavy duty K-member
brace stabilizes the front Precision sway bar kit,
suspension, provid- designed for 2005-14 Ford
ing improved control Mustang, has been extensively
and handling. Brace designed and tested on the
prevents lower control road to provide added chassis stability and improved handling. Sway
arms from distorting during extreme conditions. Brace features an bars are designed to offer the best performance and offer a direct, bolt-
adjustable sleeve to fine tune the preload. on installation. Complete kit includes hollow core, 1-3/8” diameter x
Note: Brace will only work with the OEM K-member. 3/16” wall front sway bar and solid core, 7/8” diameter rear sway bar.

45
45
45
45
2016-17 MUSTANG PRODUCTS 45
