Street Hydraulic Release Bearing
RAM78175
Ram Street Hydraulic
Force 9.5 and 10.5 Dual Disc Clutch Systems Release Bearings are per-
fect for custom builds, kit
Force 9.5 and 10.5 clutches combine the benefits of smooth drivability
and easy pedal effort with extreme holding power. The strapped floater cars, or other applications
where the standard release
plate eliminates noise at idle. Force 9.5 are suited for applications mechanism may not fit.
up to 750 horsepower, while the 10.5 is for applications up to 1,000 Bearings feature .700" travel,
horsepower. Designed as a bolt-in for late model Mustangs. Complete and work with up to a 3/4" master cylinder. Kits include the release
with a billet flywheel.
bearing, bleed kit, and mounting hardware. Fits 2005-10 Mustang with
Force 9.5 Force 10.5 T56 Transmission.
Application Part No. Part No.
Ford 4.6L, 1-1/16”-10 Spline, 6-Bolt Crank, RAM75-2260 –
164T Flywheel True Balance Billet Flywheels
Ford 4.6/5.4L, 1-1/16”-10 Spline, 8-Bolt Crank,
164T Flywheel RAM75-2200 RAM80-2200 Flywheel is ready to bolt-in out of the box. Unit
Ford 4.6/5.4L, 1-1/8”-26 Spline, 8-Bolt Crank, is CNC machined, surface ground parallel to the
164T Flywheel RAM75-2220 RAM80-2220 crank flange, and precision balanced. Steel or
Ford 5.0L, 2011-14, 1”-23 Spline, 164T Flywheel RAM75-2230 RAM80-2230 aluminum.
Make Ring Gear Balance Steel Aluminum
Small Block 5.0L 1993-95 157-Tooth 50 Oz./In. RAM1525 RAM2525
Force 10.5N Dual Disc Clutch System 2011-14 Mustang 5.0L,
RAM80-2220N 8-Bolt 164-Tooth Internal RAM1545 RAM2545
Engineered for 1996-04 Ford Mustang Small Block 4.6L 8-Bolt 164-Tooth Internal RAM1545 RAM2545
4.6L / 2006-10 Shelby GT500 5.4L with
8-bolt crank flange and 26-spline input Hydraulic System Adjuster
shaft, clutch system offers exceptional hold-
ing power, yet includes the ability to endure RAM78300
some slippage without losing it’s coefficient of friction. Clutch uses a Allows adjusting clutch pedal position
sintered iron, 900 series disc with metallic facing and sprung hub. in virtually any vehicle using an internal
Note: Kit should only be used with Ram steel or aluminum flywheel of hydraulic slave cylinder. Unit plumbs
excessive wear to the friction surface will occur.
inline with the feed line from the slave cylinder and is compatible with
all factory or aftermarket hydraulic clutch release bearings.

Ring And Pinion Installation Components
Ratech offers a complete line of differential service parts. Whether installing a new set of gears or making a repair, Ratech has just what is needed.
Smart Sleeve
Innovative new crush sleeve design offers eased installation and improved reliability. During installation, the Smart Sleeve requires only
130-150 ft./lbs. of torque, compared to the 300-400 ft./lbs. required for traditional crush sleeves, and the unique design offers improved
cycle duty when compared to solid spacers.
Installation Kits RAT11001
Basic Kit: pinion shims, crush sleeve, pinion seal, cover gasket
Installation Kit: pinion shims, carrier shims, crush sleeve, pinion seal, pinion nut, ring gear bolts, cover gasket
Bearing Kit: pinion and carrier bearings
Complete Set: All small parts and bearings to com plete a ring and pinion installation.
Housing Basic Inst. Kit Installation Kit Bearing Kit Complete Kit
;dgY -#-
2007-12 GT500, Roush, Shelby, Saleen '10-14 All Mustangs RAT405K RAT105K — RAT387K
1994-09 Mustang RAT405K RAT105K RAT205B RAT305K
1994-09 Mustang (Kits Include A Smart Sleeve) — RAT4005K — RAT5005K
Individual Component Parts
Whether it's carrier bearings or just a pinion nut, Ratech components will complete the rear end overhaul.
Pinion Crush Sleeve/ Pinion Pinion Ring Gear Cover Head Tail Carrier
Housing Shims Carrier Shims Smart Sleeve Seal Nut Bolt Gasket Bearing Bearing Bearing Set
;dgY -#-
2007-12 GT500, Roush, Shelby, Saleen RAT1100 RAT1126 RAT3104/RAT11001 RAT6105 RAT1502 RAT1316 RAT5122 — RAT8003 RAT9001
2010-14 All Mustangs
1994-09 Mustang RAT1100 RAT1126 RAT3104/RAT11001 RAT6105 RAT1502 RAT1316 RAT5122 RAT7005 RAT8003 RAT9001
