Charge Motion Delete Plugs STD555-3148
Can’t use Steeda Charge Motion Plates on that
Bumpsteer Kits 2009-10 Mustang GT? Use Charge Motion Delete
Plugs instead to reduce turbulence and improve
Kits replace stock outer tie rods to keep car air flow in the intake path for up to 10 more
straight prevent bumpsteer caused by changes horsepower.
in toe during suspension movement. Kits include two spherical rod ends,
heat treated alloy steel shafts, CNC-machined aluminum collars and a
shim assortment. Heavy Duty Race Engine Mounts
Part No. Description STD555-4005
STD555-8104 ....1994-04 Mustang Sturdy mounts replace stock 2005-14 (GT
STD555-8106 ....2005-14 Mustang Bullitt / Boss) 4.6L Mustang’s Hydra-Bushing
mounts for added durability and improved
Heavy Duty Upper Rear Control Arms header clearance. Sold in pairs
Upper rear control arms are available in
heavy duty and heavy duty, double adjustable Heavy Duty Adjustable Engine Mounts
versions. Both are polyurethane bushed and Engineered for popular Mustangs,
will improve handling and traction. Double heavy duty, billet aluminum engine
adjustable arms allow adjustment of pinion mounts allow for up to 3/4" adjustment
angle for maximum traction. Sold in pairs range, providing necessary clearance to
Part No. Description superchargers and strut tower braces.
STD555-4100 ... Heavy Duty Double Adjustable Upper Rear Control Arms, Made in the USA, mounts additionally
1994-04 Mustang prevent the fatigue and sagging that is STD555-4009
STD555-4096 ... Heavy Duty Upper Control Arm 2005-10 Mustang, common to OEM units.
Lowered Vehicle Part No. Description
STD555-4098 ... Heavy Duty Upper Control Arm 2011-14 Mustang, STD555-4009 .... 2007-14 Ford Mustang GT500
Lowered Vehicle STD555-4038 .... 2016 Ford Mustang EcoBoost 2.3L
STD555-4039 .... 2015-16 Ford Mustang 5.0L
Speedometer Recalibration Drive Gears
For 1994-98 Mustang manual or automatic transmissions. Engine Cover Inserts STD555-0681
Used for speedometer recalibration when differential gear Steeda’s mirror finish, stainless steel engine
ratios have been changed. Drive Gears sold individually. cover inserts are a great addition to the engine
Part No. Description Gear Ratio bay. Fits 2011-14 Mustang 5.0L engines in
Manual Trans., 7-Tooth Drive Gear, minutes. Made in the USA.
1996-98 Cobra 5-Speed, Tremec TR-3550 4.10
STD392-STE-17271-D And TKO Heavy Duty Upper Strut Mounts
Manual Trans., 8-Tooth Drive Gear, 3.55 And
Heavy duty, direct replacement upper
1994-98 5-Speed (Except 1996-98 Cobra) 3.73 strut mounts eliminate the “popping”
STD392-STE-17271-J Auto Trans., 8-Tooth Drive Gear, 1994-98 3.55 And sound when the OEM mount fails. Mounts
3.73 also allows an extra 1° of camber in each
direction. Sold in pairs.
X2 Ball Joints STD555-8101 Part No. Description
STD555-8120 ..... 2005-10 Ford Mustang V8/V6, 2007-14 GT500
Ideal for lowered 1994-04 Mustangs, custom length ball STD555-8135 ..... 2011-14 Mustang V6/V8
joints raise the roll center, enhance handling and reduce
body roll. Oversized sway bars and/or increased
spring rates are not needed. Steeda bump 2011-14 Mustang Adjustable
steer kit (STD555-8104) is recommended. Upper Strut Mounts STD555-8137
Sold in pairs.
More extreme adjustments for caster and
Sport Spring Kits STD555-8200 camber are possible with Steeda Adjustable Upper Strut
Mounts. With stock springs, negative camber can be adjusted to –2.3
Improve the appearance and handling of degrees; with 2-1/2” coils, mounts allow up to –3.5 degrees of negative
1994-04 Mustangs without affecting ride caster. Spring size also determines the amount of camber adjustment
quality. Kit installation lowers the car ap- because of the inside size limitations of the strut tower. Positive caster
proximately 1". Each kit includes two front can be set up to .5 degrees over stock. Not recommended for street use.
and two rear coil springs. Sold in pairs
Note: Not a direct replacement for GT500. Can be made to work with
Charge-Motion PlatesSTD555-3125 GT500 Mustangs with adjustments
Charge-motion plates directly
replace the restrictive OEM plates and X11 Ball Joints STD555-8136
install between the cylinder heads Steeda’s X11 ball joints are longer and stronger,
and intake manifold of 2005-08 4.6L designed to raise the front roll center which
Mustangs. Charge-motion plates are becomes lower as a result of lowering springs or
CNC-machined from premium 6061- and air adjustable hide height system. Raising the
T6 billet aluminum plates have no nitrous ports. Sold per pair. roll center eliminates issues as cornering grip,
increased body roll, and increased understeer. Sold in pairs and fits
2011-14 Mustang.
