Page 296 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

IN-LINE FUEL FILTERS SHUT-OFF VALVES
Blue anodized aluminum fuel filters include 350 PSI max valves are ideal for use as emergency
sintered bronze 35 micron elements. Filters are fuel shut-off valves, anti-theft devices, or as drain valves.
3-1/2" long x 1-1/8" diameter. Inlet Outlet Overall Body
Fuel Filter Rep. Element Part No. Size Size Length Material
Description Part No. Part No. EAR230501ERLP 3/8" NPT 3/8" NPT 1-3/4" Chrome Plated Brass
In-Line Fuel Filter, -6AN Male Ends EAR230106ERLP EAR230107ERLP Female Female
In-Line Fuel Filter, -8AN Male Ends EAR230108ERLP EAR230107ERLP 3/8" NPT
EAR230502ERLP -6AN Bulkhead 2-3/4" Red Anodized Aluminum
Female
IN-LINE FUEL AND OIL FILTERS EAR230503ERLP 3/8" NPT -8AN Bulkhead 2-3/4" Red Anodized Aluminum
Billet aluminum fuel and oil filters are fitted with Female
cleanable screen type elements. Blue anodized EAR230504ERLP 1/2" NPT 1/2" NPT 2-1/4" Chrome Plated Brass
Female
Female
fuel filters use 85 micron elements, while red 1/2" NPT
anodized oil filter units include 140 micron EAR230505ERLP Female -10AN Bulkhead 2-3/4" Red Anodized Aluminum
elements.
Blue Fuel Filter Red Oil Filter EZ-BEADER TUBING BEADER
Description Part No. Part No.
In-Line Filter, -6AN Male Ends EAR230206ERLP EAR230306ERLP Required when joining flexible hose to rigid tubing, specialized tool provides
In-Line Filter, -8AN Male Ends EAR230208ERLP EAR230308ERLP a perfectly positioned radiused bead on aluminum tubing with .035"-.065" wall
In-Line Filter, -10AN Male Ends EAR230210ERLP EAR230310ERLP thickness.
Part No. Tube O.D.
EAR008ERLP 3/8"
EAR009ERLP 1/2"
EAR010ERLP 5/8"
EAR011ERLP 3/4"
EAR013ERLP 1-1/4"

MIG WELDER’S PLIERS
MIG WELDERS EAS19015
Powerful welders are capable of completing Specialized, heavy duty pliers include knurled surfaces
nearly any welding task, including mild steel, to secure tips and nozzles, easing installation. Squared-off,
stainless steel or aluminum (Mig 175 only). spring-loaded tips remove spatter, while the built-in wire
Units include infinitely adjustable heat and cutter adds convenience.
wire settings, while the “Quick set” chart
provides the proper settings for material and thickness. MIG WELDING ACCESSORIES
Backed by a 3-year warranty, unit is sold complete with Tweco-style gun,
ground cable, contact tips, regulator with hose, 2 lb. spool of MIG wire and Part No. Description
Contact Tips, Five Pack Of .030",
instruction book. Bottle not included. Choose from 135 or 175 amp versions. EAS12224 Works With .030" MIG Or Flux Core Wire
Part No. Description
EAS12011 .........MIG 135 Amp Welder EAS12227 Solid MIG Wire, .030",
EAS12012 .........MIG 175 Amp Welder, Includes Spool Gun For Aluminum Use With .030" Contact Tips, 4" Spool EAS12224
MIG WELDER SPECIFICATIONS TIG200 AC/DC WELDER
MIG 135 Amp MIG 175 Amp
Power Requirements EAS12746
110V 220V
Welding Capability Welder operates on either 110vAC, 15amp circuit or 220vAC,
(Mild Steel) 24 ga. - 1/4" 24 ga. - 5/16" 30 amp circuit. Offers affordable professional quality TIG weld-
Welding Capability ing on aluminum, stainless, sheet metal, and tube or bar stock
(Aluminum) No 14 ga. - 1/4" with precise welding of thinner gauge materials up to 1/4"
Mild/Stainless/ thick. Also will weld aluminum. A high frequency start gives
Material Mild/Stainless
Aluminum precise arc control. The square wave inverter allows
Welding Range 25-135 Amp 30-175 Amp accurate aluminum welding, “WP-17” type torch accepts common cups
Duty Cycle 20% @ 90 amp 30% @ 135 amp and collets and up to 1/8" electrodes. Duty cycle 45% at 150 amps.
Wire Speed 39-468 IPM 58-471 IPM
TIG WELDER 200 AMP DC
EAS14100
MIG WELDER COVER Weld steel or stainless up to 3/16" thick. Premium
EAS20131 quality unit includes pre-set post and pre-flow gas,
Custom made to fit the MIG 135 and MIG 175 overload protection and adjustable amperage
welder, heavy duty tear resistant cover protects the control through trigger switch or foot pedal
welder from dust and debris. operation. Adjust amperage from 10 to 200 amp.
Accepts all common electrodes and collets up to 1/8".
Unit is operable as 110 or 220 volt.
