Page 690 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

CHROME WIDE 5 ELASTIC DAMPENER DRIVE
WHEEL LOCATOR WIN6635C FLANGE REPLACEMENT SPOOLS
For 8-bolt wide 5 hubs. Round urethane spools are available in three durometer hardnesses and are
sold individually.
Description
Part No.
VITON WIDE 5 HUB SEAL WIN1149B Black, Soft 80 Durometer
WIN7210V WIN1149R Red, Med 90 Durometer
Fits popular wide 5 hubs. WIN1149Y Yellow, Hard 95 Durometer
2-7/8" ALUMINUM FRONT SPINDLES CROWN SPLINE DRIVE FLANGE
Spindles are constructed from durable, forged 7075-T6 aluminum and are WIN1279AX5
sold complete with king pin and cap. May be used with Winters 2-7/8" Wide 5 True, crown spline coupler features a billet
front hubs. aluminum 5-bolt flange. Designed for use with
cambered spindles, drive flange may be used
WIN3796 with 31/24 spline crown spline axles, solid or
gundrilled.
WIN3795 Part No. Description
Related Component
WIN2266 Drive Flange Studs, Each
2-1/2" GRAND NATIONAL FORD 9"
FULL FLOATING REAR AXLE ASSEMBLIES
Part No. Description
WIN3795 Left Front Spindle Ford 9" rear axle assemblies, designed specifically for oval track applica-
WIN3796 Right Front Spindle tions, are offered in a variety of offsets and tube styles. Platinum 5 x 5", 4140
heat treated 2-1/2" Grand National hubs, 11.75" dia. x .810" thick rotors and
solid axles are included. Differential case, carrier/spool, ring and pinion as-
2-7/8" WIDE 5 REAR HUB KIT sembly and related components must be purchased separately.
WIN3750
Polished, permanent mold aluminum hub is sold
complete with 5-bolt, 7075-T6 billet aluminum inverted
drive flange, bearings, seal kit and steel lock nut kit. WIN95345-S1-P
Complete hub assembly, which includes oil fill and
level plug, weighs just 6 lbs., 9 ozs.
Part No. Description
Replacement Components
WIN3698 Billet Aluminum Inverted Drive Flange
WIN7289V Seal Housing
WIN8658 Bearing Cup And Cone Set Part No. Description Width
Axle Assemblies
WIN95345-S1-P 9" Axle, Steel Hubs 60"/Centered
2-7/8" WIDE 5 FRONT HUB KIT WIN95345-S2-P 9" Axle, Steel Hubs 60"/2" Offset
WIN95345-S5-P
9" Axle, Steel Hubs
WIN3750F WIN95345-M1-P 9" Axle, Machined Steel Tubes 62"/Centered
60"/Centered
Manufactured from permanent mold aluminum Bare Housing Only
with a polished finish, hub kit is sold complete with WIN95345S-60C 9" Axle 60"/Centered
5-bolt dust cap, bearings, seal kit and steel lock nut kit.
Complete hub assembly, which includes oil fill and FORD 9" STEEL SPOOL
level plug, weighs just 6 lbs.
Part No. Description WIN95034-15S
Replacement Components Manufactured from forged alloy steel that has been fully
WIN3278 Gasket, Dust Cap heat treated and stress analyzed, Ford 9" spool has been
WIN3289 5-Bolt Aluminum Dust Cap scalloped and drilled to minimize rotating weight. Spool
WIN7289V Seal accepts 31-spline axles and has 1.782" bearing journals.
WIN8658 Bearing Cup And Cone Set
FORD 9" ALUMINUM HOUSING
WIN5243
A lightweight re place ment for the steel
WHEEL STUDS Ford 9" housing, the Winters alu mi-
WIN1701 WIN1684
Part No. Description num hous ing offers many advantages:
WIN1684 Flanged Stud, 5/8"-18 (Fine), 3.188" O.A.L. Includes push-in 3" side tube as sem blies,
WIN1701 Flanged Stud, 5/8"-11 (Coarse), 2.500" O.A.L. mak ing re place ment easy and in creased sump
Press-In Stud Kit, 1" Longer With QuickStart, capacity to keep differential assembly cooler during long races. An oversize
WIN8940
Includes (5) 5/8"-11 x 4" Long Studs inspection-filler plug per mits a quick, easy check of ring gear condition.
WIN8941 Screw-In Stud Kit, Includes (5) 5/8"-11 x 2-7/8" Screw-In Studs

689
