STAINLESS STEEL BRAIDED CPE RACE HOSE
Stainless steel outer braid delivers durability, heat resistance and great looks. The elastomer chlorinated polyethylene
(CPE) inner tube is compatible with a wide range of liquids.
Size I.D. O.D. 3 Feet 6 Feet 10 Feet 15 Feet 20 Feet
-6 .344" .547" XRP300306 XRP300606 XRP301006 XRP301506 XRP302006
-8 .438" .641" XRP300308 XRP300608 XRP301008 XRP301508 XRP302008
-10 .562" .797" XRP300310 XRP300610 XRP301010 XRP301510 XRP302010
-12 .688" .928" XRP300312 XRP300612 XRP301012 XRP301512 XRP302012
ALUMINUM HOSE ENDS
XRP hose ends are aviation nipple and cutter style to prevent blow off and leakage problems. Fittings are built from heat treated aluminum and are race ready.
Red/Blue Black Red/Blue Red/Blue Black Red/Blue
Swivel Swivel Non-Swivel Swivel Swivel Non-Swivel
Part No. Part No. Part No. Size Part No. Part No. Part No. Size
Straight 90° Hose Ends
XRP100004 XRP100004BB – -4 – – XRP109004 -4
XRP100006 XRP100006BB – -6 XRP209006 XRP209006BB XRP109006 -6
XRP100008 XRP100008BB – -8 XRP209008 XRP209008BB XRP109008 -8
XRP100010 XRP100010BB – -10 XRP209010 XRP209010BB XRP109010 -10
XRP100012 XRP100012BB – -12 XRP209012 XRP209012BB XRP109012 -12
XRP100016 XRP100016BB – -16 XRP209016 XRP209016BB XRP109016 -16
– XRP100020BB – -20 – XRP109020BB* – -20
30° Hose Ends 120° Hose Ends
XRP203006 XRP203006BB XRP103006 -6 – – XRP112004 -4
XRP203008 – XRP103008 -8 XRP212006 XRP212006BB XRP112006 -6
XRP203010 XRP203010BB XRP103010 -10 XRP212008 – XRP112008 -8
XRP203012 XRP203012BB XRP103012 -12 XRP212010 XRP212010BB XRP112010 -10
XRP203016 XRP203016BB – -16 XRP212012 XRP212012BB XRP112012 -12
45° Hose Ends XRP212016 XRP212016BB – -16
– – XRP104504 -4 – XRP112020BB* – -20
XRP204506 XRP204506BB XRP104506 -6 150° Hose Ends
XRP204508 XRP204508BB XRP104508 -8 XRP215006 – XRP115006 -6
XRP204510 XRP204510BB XRP104510 -10 XRP215008 – XRP115008 -8
XRP204512 XRP204512BB XRP104512 -12 XRP215010 – XRP115010 -10
XRP204516 XRP204516BB – -16 XRP215012 XRP215012BB – -12
– XRP104520BB* – -20 XRP215016 – – -16
60° Hose Ends 180° Hose Ends
– – XRP106004 -4 – – XRP118004 -4
XRP206006 XRP206006BB XRP106006 -6 XRP218006 XRP218006BB XRP118006 -6
XRP206008 XRP206008BB XRP106008 -8 XRP218008 XRP218008BB XRP118008 -8
XRP206010 XRP206010BB XRP106010 -10 XRP218010 XRP218010BB XRP118010 -10
XRP206012 XRP206012BB XRP106012 -12 XRP218012 XRP218012BB XRP118012 -12
XRP206016 – XRP106016 -16 XRP218016 – XRP118016 -16
– XRP106020BB* – -20 * All size -4 and -20 hose ends are non-swivel.
* All size -4 and -20 hose ends are non-swivel.
ALUMINUM PUSH-ON HOSE ENDS
Machined from aluminum alloy with red and blue or black anodized finish, hose ends are only compatible with push-on hose, NOT stainless steel braided hose. All
hose ends are JIC 37°. See Page 699 For push-on hose clamps and pliers.
Red/Blue Black Red/Blue Black
Part No. Part No. Size Part No. Part No. Size
Straight 120°
XRP230004 XRP230004BB -4 XRP231204 – -4
XRP230006 XRP230006BB -6 XRP231206 XRP231206BB -6
XRP230008 XRP230008BB -8 XRP231208 XRP231208BB -8
XRP230010 XRP230010BB -10 XRP231210 XRP231210BB -10
XRP230012 XRP230012BB -12 XRP231212 XRP231212BB -12
45° 150°
XRP234504 XRP234504BB -4
XRP234506 XRP234506BB -6 XRP231506 XRP231506BB -6
XRP234508 XRP234508BB -8 XRP231508 – -8
XRP234510 XRP234510BB -10 XRP231510 – -10
XRP234512 XRP234512BB -12 XRP231512 XRP231512BB -12
60° 180°
XRP236006 XRP236006BB -6 XRP231806 – -6
XRP236008 XRP236008BB -8 XRP231808 XRP231808BB -8
XRP236010 XRP236010BB -10 XRP231810 – -10
XRP236012 XRP236012BB -12 XRP231812 – -12
90°
XRP239004 XRP239004BB -4
XRP239006 XRP239006BB -6
XRP239008 XRP239008BB -8
XRP239010 XRP239010BB -10
XRP239012 XRP239012BB -12
