PReMISe SIte MaIntenanCe
S BaRRIeR SySteMS

tRaFFIC LIne - HeaVy DUtyPaLLet
RaCKInG PROteCtORS

Conform to DIN 4844 Safety Guidelines
Provide protection from vulnerable frame ends & uprights
Made in Steel & powder coated Yellow with Black bands
Can effectively be used to protect machines, partitioning,mezzanine
support columns, concrete columns etc
Right angle - for corner protection bolted on 2 sides
U-Profile - for three sided
protection bolted on 3 sides
TUV tested for strength & build quality
Overall Size Fixing Bolts Required Weight
Description Model
H x W x Gauge mm per protector kg
400 x 160 x 5 4 8 197.15.928
400 x 160 x 6 4 9 197.13.182
Right Angle
800 x 160 x 6 4 16 197.14.605
1200 x 160 x 6 4 22 197.18.380
U-Profile 400 x 160 x 6 6 11 197.18.365
Surface Fixing Bolts1 2 x 100 - 0.2 100.17.393
tRaFFIC LIne -COLLISIOn
PROteCtIOn BaRS
Protect your shelves, cabinets, machinery etc
Low profile design allows easy access to pedestrians
Size: 76mm Dia., 3mm wall thickness
Surface mounted with extra strength base plates
Powder coated in Yellow with Black bands
Overall Size Weight
Description Model
H x W mm kg
86 x 400 5 195.13.478
Protection Bars 86 x 800 7.5 195.19.220
86 x 1200 10 195.14.143
Fixing Bolts (4 per guard) 12 x 100 0.2 100.17.393

tRaFFIC LIne - IMPaCt PROteCtIOn RaILInG SySteM - tUV aPPROVeD

Extremely strong & versatile protective railing system
Manufactured in structural Steel & hot dip Galvanised finish with Yellow
powder coat - ideal for external use
TUV tested for strength & build quality
Posts: 100 x 100mm section
Base Plate: 200 x 200mm
Surface fixing 4 bolts
Lateral Rails: 120 x 80mm section

Overall Size Weight
Description Model
H x W mm kg
Bollard 1000 x 100 x 100 16 194.13.700
End Post 500 x 100 x 100 10 194.15.765 Cross Bar Weight
Centre Post 500 x 100 x 100 10.5 194.18.142 120 x 80mm kg Model
o
90 Angle Post 500 x 100 x 100 10.5 194.15.032 1000 9.5 194.16.672
End Post 1000 x 100 x 100 17 194.13.501 1200 11.5 194.14.863
Centre Post 1000 x 100 x 100 18 194.13.894 1500 14 194.16.449
o
90 Angle Post 1000 x 100 x 100 18 194.15.572 2000 18 194.13.826
238 (For more information, visit www.loc8.ae or call toll free 800-LOC8 (5628
