P. 1409
71-3
Communication system - Horn
Horn
Replacement
1. Disassemble the horn button (refer to “Chapter 41 Steering mechanism – steering gear,
Check and repair”)
2. Disassemble left horn assembly
(a). Disconnect the insert part.
71
(b). Loose the bolt and disassemble the horn.
3. Disassemble the right horn assembly
Hint:
The steps to disassemble right horn assembly are same with that of left horn assembly.
4. Assemble horn button (refer to “Chapter 41 Steering mechanism – steering gear,
Check and repair”)
5. Assemble left horn assembly
(a). Fasten the bolt and connect the insert
part.
