ROTARY SCREW AIR COMPRESSORS

(100% OIL FREE)

LENTO SERIES

Direct Drive - Water Injected

Oil-free LENTO series of ALMiG Kompressoren GmbH deliver maximum cost-effectiveness in compressed air treatment Not only is there demand for high-quality, 100% oil-free compressed air in the pharmaceutical, foodstuffs, electrical engi-
by precisely matching the volume flow to the exact “CLASS 0” compressed air requirement and through low compressed neering and medical industries, but wherever products of the highest quality are produced. Only water, the most natural
air outlet temperatures and minimized service and maintenance costs. of all raw materials, is used in the compression process of LENTO Series.

50 Hz speed-controlled
Operating Volume flow acc. to ISO 121 Rated Motor
LENTO Length Width Height
over-pressure (Annex C-2009) Power
Main Features: bar min. (m 3 /min) max. (m 3 /min) KW mm mm mm
15
Compressor Water circuit 15 5-10 1.01 2.34 18.5 1880 850 1660
5-10
18
850
1660
1880
1.01
2.87
Single-stage, water-injected Closed water circuit, integrated water treatment 22 5-10 1.01 3.38 22 1880 850 1660
850
Low final compression temperatures (<60°C) Multi-stage separation for dry compressed air 30 5-10 1.01 4.30 30 1880 1400 1660
2300
5.08
30
2.04
5-10
1560
31
SCD motor Direct drive 37 5-10 2.04 6.14 37 2300 1400 1560
IP 55 ISO F protection class Zero-loss power transfer 45 5-10 2.04 7.13 45 2300 1400 1560
Compact / High-performance / Reliable SCD frequency converter 55 5-10 2.04 8.19 55 2300 1400 1560
1400
45
1769
2674
8.18
2.49
46
5-10
Integrated refrigeration dryer with 3 jobs: The integrated power pack; acc. to EMC guidlines 56 5-10 2.49 9.86 55 2674 1769 1400
Producing fresh water for generating the coolant Air Control P 75 5-10 2.49 12.46 75 2674 1769 1400
1500
1927
76
3448
13.82
75
4.06
5-10
Ensuring optimum biological water quality The compressors’ intelligence; thinks, monitors and 90 5-10 4.06 16.43 90 3448 1500 1927
Delivering dry compressed air at the inlet records 110 5-10 4.06 19.60 110 3448 1500 1927
From 15 to 75 kW (Air Cooled & Water Cooled)
From 76 to 110 kW (only Water Cooled)
