Silentblocs and Bushings

KL-0215-37 M25
KL-0215-37 M25
Hydraulic Foot Pump

The KL-0215-37 M25 hydraulic foot pump is designed to drive our pressing and
pulling devices with the KL-0040-2500 hydraulic cylinder (17t). The hydraulic pressure
and necessary force can be monitored while operating the pump at pressure gauge
KL-0040-2528 (supplied with the tool set). The pressure gauge features an additional
tonne scale which is specifically adapted to our KL-0040-2500 hydraulic cylinder
(17t).

Advantage:
Both hands free to work.

Technical Data:
Scope of Delivery:
Weight: 11kg
KL-0215-37 M25 Hydraulic Foot Pump
Max. Pressure: 700bar
Part No. Description Qty
KL-0215-370 Hydraulic Foot Pump, without Hose 1 Note:
Hydraulic foot pump with pressure gauge, suitable for the hydraulic cylinder KL-0040-2200 (10t)
KL-0215-371 Hydraulic Hose, 2.5m, with Hose-Side Coupling 1
or KL-0040-2800 (28t), available upon request.
KL-0215-322 Cylinder-Side Coupling, 1/4" NPT 1
4 KL-0040-2520 Adaptor, 3/8" NPT to 1/4" NPT 1 1
KL-0040-2528
Pressure Gauge
KL-0215-37
Hydraulic Foot Pump
Like the KL-0215-37 M25, however, without Pressure Gauge.

KL-0215-36 M25
KL-0215-36 M25
Hydraulic Pump (Pneumatic)

The pneumatic hydraulic pump KL-0215-36 M25 is designed to be used as a drive for
hydraulic cylinders.
Compressed air is used to power the hydraulic pump. The pump is operated by a foot
pedal with 3 positions - for pumping, holding and releasing.

Advantage:
Both hands free to work.

Technical Data:
Maximum Pressure: 700bar
Scope of Delivery: Operating Pressure: 8-12 bar
KL-0215-36 M25 Hydraulic Pump (Air-Driven ) Weight: 8kg
Part No. Description Qty
KL-0215-360 Hydraulic Pump (without Hose) 1
KL-0215-362 Hydraulic Hose, 2.5m, with Hose-Side Coupling 1
KL-0215-36
KL-0215-322 Cylinder-Side Coupling1/4" NPT 1
KL-0040-2520 Adaptor 3/8" NPT to 1/4" NPT 1
KL-0040-2529 Pressure Gauge 1 Hydraulic Pump (Pneumatic)
Like the KL-0215-36 M25, however, without Pressure Gauge.
