Style "D" Chasers


              High Speed Steel – Special Ground Thread



      THREADING  For Geometric  and similar die heads.   Chamfer Angle:
                         ®
            NOTE: “D” and “DS” chasers for up to and including
            3/4” DIE HEADS are interchangeable.

                                                    33° Regular Style &
                                                    45° Projection Style
                                                    10° Cutting Edge Grind
            5/16 Inch Die Head                                  9/16 Inch Die Head

              Style/List No.    Sizes-Thread Available  Price    Style/List No.    Sizes-Thread Available   Price
                                                       Each                                                 Each
                                                                             6-36, 6-48, 8-40,
                           0-70, 1-56, 2-48, 4-32, 4-36, 4-64,               8-48, 10-48, 10-56,
                           5-32, 5-36, 5-48, 5-56, 6-30,                     10-80,12-20, 12-32,
                           6-36,6-48, 5/32-32, 5/32-36, 8-30,                12-36, 12-40, 12-48, 14-20,
                           8-40, 8-48, 9-28, 10-30, 10-36,                   14-24, 7/32-32, 1/4-27,
             Right Hand    10-40, 10-48,10-56, 12-20, 12-26,                 1/4-32, 1/4-36, 1/4-48,
             Special Thread  12-32, 12-36, 12-40, 12-48,   250.00            1/4-56, 5/16-27, 5/16-32,
                           14-20, 14-24, 7/32-32,                            5/16-36, 5/16-40, 5/16-48,
             List No. 711S  1/4-24, 1/4-27, 1/4-32,               Right Hand   3/8-18, 3/8-20, 3/8-27, 3/8-28,
                           1/4-36, 1/4-40, 1/4-48, 1/4-56,        Special Thread  3/8-32, 3/8-36, 3/8-40,  295.00
                           5-16-20, 5/16-27, 5/16-28, 5/16-30,               3/8-48, 7/16-16, 7/16-18,
                           5/16-32, 5/16-36, 5/16-40, 5/16-48,    List No. 712S  7/16-24, 7/16-27, 7/16-28,
                           3/8-32                                            7/16-32, 7/16-36, 7/16-40,
                                                                             15/32-24, 1/2-12, 1/2-16, 1/2-18,
                                                                             1/2-24, 1/2-27, 1/2-28,
                                                                             1/2-32, 1/2-36, 1/2-38,1/2-40,
                           0-70, 1-72, 1-56, 2-48, 4-32, 4-36,               1/2-48, 1/2-64, 9/16-16, 9/16-20,
                           4-64, 5-32, 5-36, 5-48, 5-56, 6-30,               9/16-24, 9/16-27, 9/16-28,
                           6-32, 6-48, 6-52, 8-30, 8-40,                     9/16-32, 5/8-32
             Right Hand    8-48, 10-28, 10-30, 10-36, 10-40,
             Special Thread  10-44, 10-48, 12-32, 12-36, 12-40,              6-30, 6-36, 6-48, 4-32, 4-36, 4-64,
             Projection    12-56, 14-24, 3/16-24, 3/16-32,   280.00
                           3/16-64, 1/4-24, 1/4-27, 1/4-32,                  5/32-32, 8-40, 10-56, 10-80,
             List No. 711SP  1/4-36, 1/4-38, 1/4-40, 1/4-48,                 12-32, 1/4-32, 1/4-56, 9/32-20,
                           1/4-56, 5/16-20, 5/16-27, 5/16-28,     Right Hand   5/16-20, 5/16-27, 5/16-28, 5/16-36,
                           5/16-32, 5/16-36,                      Special Thread 5/16-40, 5/16-48, 3/8-18,
                           5/16-40, 5/16-48                       Projection  3/8-20, 3/8-28, 3/8-32, 3/8-40, 3/8-48,  310.00
                                                                             7/16-15, 7/16-16, 7/16-18, 7/16-24,
                                                                  List No. 712SP 7/16-27, 7/16-28, 7/16-40,
                                                                             1/2-16, 1/2-18, 1/2-24,
             Left Hand     4-32, 4-36, 5-48,                                 1/2-32, 1/2-40, 1/2-48,
             Special Thread  6-36, 6-40, 8-40,        320.00                 9/16-16, 9/16-20,  9/16-27,  10x.75mm
                           1/4-24, 1/4-32,
             List No. 711SL  1/4-40, 5/16-32
                                                                             4-32, 4-36, 5-48, 6-36,
                                                                  Left Hand
             Left Hand                                            Special Thread  8-40, 1/4-24,
             Special Thread                                                  1/4-32, 1/4-40, 5/16-32,      330.00
             Projection    5/16-32                    325.00      List No. 712SL  3/8-32, 7/16-24,
                                                                             1/2-32, m4.5x.75
             List No. 711SLP




            Bench Centers


              Features:
              • Quick release centers.                    For accurate concentricity inspection.
              • M.T.2 Centers are hardened and ground.
              • Indicator Holder included.                 Distance  Swing    Overall  Weight  Tool No.  Price Each
                                                           Between
              • Hand Scraped ways, adjustable gibs.         Center            Length
              • Head Stock can be adjusted lengthwise and
                locked securely in any position by special   16"      12"      30"     125 lbs.  J6500100  1225.00
                lever type handle.                           32"      19"      48"     395 lbs.  J6500200  2940.00
