Metric Style "D" Chasers

High Speed Steel – Ground Thread

For Geometric and similar die heads.
®
NOTE: “D” and “DS” chasers for up to and including
3/4” DIE HEADS are interchangeable. Chamfer Angle: THREADING
33° Regular Style &
45° Projection Style
10° Cutting Edge Grind
5/16 Inch Die Head - Metric 1 Inch Die Head - Metric

Style/List No. Sizes-Thread Available Price Style/List No. Sizes-Thread Available Price
Each
Each
1.7 x .35, 2.3 x .40, 6.0 x 1.0, 7.0 x 1.0,
2.5 x .45, 2.6 x .45, 8.0 x .75, 8.0 x 1.25,
Right Hand 3.0 x .50, 3.5 x .60, 9.0 x 1.25, 10.0 x 1.25,
4.0 x .50, 4.0 x .70, 4.5 x .75, 198.00 Right Hand 10.0 x 1.5, 11.0 x 1.50,
List No. 711M 5.0 x .80, 6.0 x .50, 12.0 x 1.0, 12.0 x 1.25,12.0 x 1.75, 310.00
6.0 x 1.0, 8.0 x .75, List No. 713M 14.0 x 1.25, 14.0 x 1.5,
8.0 x 1, 8.0 x 1.25 16.0 x 1.50, 18.0 x 1.25 18.0 x 2.50
22 x 1.50
2.6 x .45, 3.5 x .60
Right Hand
Projection 4.0 x .50, 4.0 x .70, 10.0 x 1.5, 12.0 x 1.75,
4.50 x .75, 5.0 x .80, 6.0 x .50, 245.00 Right Hand 14.0 x 1.5, 18.0 x 1.5,
6.0 x 1.0, 7.0 x 1.0, Projection
List No. 711MP 18.0 x 2.5, 20.0 x 1.5, 330.00
8.0 x 1.0, 8.0 x 1.25 22.0 x 2.5, 22.00 x 1.50, 24.0 x 1.5
List No. 713MP
24 x 3.00
9/16 Inch Die Head - Metric 1-1/4 Inch Die Head - Metric
Style/List No. Sizes-Thread Available Price Style/List No. Sizes-Thread Available Price
Each Each
3.0 x .50, 3.5 x .60 12.0 x 1.75,
4.0 x .70, 5.0 x .80, 14.0 x 2.0,
6.0 x .50, 6.0 x 1.0, 18.0 x 2.5,
Right Hand Right Hand
7.0 X 1.00, 8.0 X .50, 250.00 20.0 x 1.5, 370.00
List No. 712M 8.0 x .75, 8.0 x 1.25, List No. 714M 22.0 x 2.5,
9.0 X 1.25, 10.0 X 1.50, 24.0 x 1.5,
11.0 X 1.50, 12.0 X 1.50, 27.0 x 3.00
12.0 X 1.75, 14 x 1.25 30.0 x 3.5
3.0 x .50, 3.5 x .60
4.0 x .70, 4.5 x .75 16.0 x 2.00, 18.0 x 2.5,
Right Hand 5.0 X .75, 5.0 x .80, Right Hand 20.0 x 1.5, 20.0 x 2.5,
Projection Projection
6.0 x .50, 6.0 x 1.0, 278.00 22.0 x 2.5, 24.0 x 2.0, 395.00
8.0 x 1.00, 8.0 x 1.25, 9.0 X 1.25 24.0 x 3.0, 30.0 x 1.5,
List No. 712MP List No. 714MP
10.0 X 1.50, 11 x 1.50, 12.0 X 1.00, 30.0 x 3.5
12.0 X 1.50, 12.0 X 1.75

Hardness Testers

Rockwell System
Standard Accessories Features:
• 5-3/4” Testing Table Automatic weight selection
• 2-3/16” Testing Table Specifications:
• 2-3/16” Testing Table with “V” groove Maximum Load (kgf.): 150
• 120° Diamond Penetrator Load Range (kgf.): 60, 100, 150
• 1/16” Steel Ball Penetrator Initial Range Load (kgf.): 10
• Rockwell A Test Block Maximum Test Height: 4-1/4”
Depth of Throat: 5-1/4”
• Rockwell B Test Block Size of Base: 7x18”
• Rockwell C Test Blocks (3pcs.) Machine Height: 24-1/2”
• Screwdrivers (2pc.) Approx. Net Weight: 150 lbs.
• Instruction Manual Tool No. Price Each
• Dustproof Cover PR1705500 1755.00
