Motor Positioners – Bi-Directional
Used for horizontal adjustment of the motor position in both direction of the horizontal plane.
Motor Positioners – Tri-Directional
(Motor feet are drilled & tapped) Vertical jack screws (red) are removed after the motor is shimmed.
Motor Positioners – Vertical Jack Screws
(Motor feet are drilled & tapped) Vertical jack screws (red) are removed after the motor is shimmed.
Shaft Cooler
Cast aluminum shaft coolers dissipate the heat transferred to the shaft from the airstream protecting
the fan bearings. Recommended for applications over 300°F. Bore size is needed if ordered as just a
stand-alone part.
Slide Gate Damper (Cast Aluminum Pressure Blowers)
Dampers feature cast aluminum frame with galvanized steel gate. Available on inlet or outlet. Slide
gate type dampers provide manual adjustment of airflow and flexibility to meet any application.
