FAN-PEDIA MOTOR POSITIONS FOR
Published by AEROVENT.COM
Aerovent BELT DRIVEN FANS
©2017
CENTRIFUGAL FANS
Note: see technical descriptions for
restrictions on certain discharges for
Arrangements 1, 3 & 3F

W AKA
AKA “R”
“L”

X
Z W * L R

Y Z

Arrangements 1 & 3 Arrangement 3F Arrangement 9

Standard Motor Position: CW (L) / CCW (R)
* Motor Position (L) is normally ordered
with F1 Conduit Box.

Standard

R F1 F2

L Sizes 122-365 (Vent Sets) Sizes 402+ Motor Mounted

Motor Mounted on Bottom of on Side of Pedestal Frame
Pedestal (Adjustable Plate) (Slide Base) Conduit Boxes
viewed from drive side of motor
Arrangement 9F Arrangement 10 (looking at motor shaft)

Standard Motor Position: CW (L) / CCW (R)
