FAN-PEDIA MOTOR POSITIONS FOR
Published by AEROVENT.COM
Aerovent BELT DRIVEN FANS
©2017
PLENUM FANS
Optional Standard
(O) (S) (TC) Top Center
*
L R
Arrangement 3HS Arrangement 3HA Arrangement 3SM
Belt Drive - Horizontal with Top Mounted Motor Belt Drive - Horizontal with Top Mounted Motor Belt Drive - Horizontal With Side Mounted Motor
with Slide Base Motor Mount with Adjustable Motor Base with Slide Base Motor Mount
Standard: Motor Position (R)
* Motor Position (L) is normally ordered with F1
Conduit Box. Select F2 if clearance issues.
(O) Optional
(TC) Standard
Top Center F1 F2
(S) Standard
Conduit Boxes
Arrangement 3VA Arrangement 3VS viewed from drive side of motor
Belt Drive - Vertical with Adjustable Belt Drive - Vertical with Slide Base (looking at motor shaft)
Motor Base Motor Mount
