FAN-PEDIA PROPELLERS
Published by AEROVENT.COM
Aerovent OVERVIEW
©2017

Steps for configuring an axial fan

Step #1 Step #2 Step #3
Select the model/propeller type What direction do you want the air to flow? Which direction does the propeller need to
(i.e. Aerovent Model TA with “L” Propeller) rotate to achieve the desired airflow direction?

air passing through the
Prop then over Motor
(Airflow = PM)
aka: Hub on Intake

or

air passing over Motor
then through the Prop
(Airflow = MP)
aka: Hub on Discharge

See following pages for addition information on propeller types by model, airflow direction and propeller rotation.

30
