P. 249
Temperature and ambient conditions monitoring
Infrared temperature-measuring instruments
Infrared temperature measuring instruments
Application: Input for thermocouple sensor NiCr-Ni (type K) Two laser beams for indicating the measuring
For measuring surface temperatures of rotating or Ident. No. 041: field size
live components HOLD/max./min./difference, additionally with LOCK function (continuous measurement)
Execution: AVG (average from measurement series) and Response time < 1 second
HOLD /max. function
lock (continuous measurement)
Error limit ±2% or ± 2°C Adjustable emission degree 0.10 to 1.01 Battery life 18 hours in continuous operation
Ident. No. 020: Laser point (class II) for aiming (switchable), 2 Adjustable acoustic alarm
HOLD/max./min./difference laser beams for indicating the measuring field scope of supply and services:
Adjustable emission degree 0.10 to 1.00 size With battery in case.
Laser point (class II) for aiming (switchable) Ident. No. 045:
Ident. No. 020–041: IP 54 splash-proof Technical Data:
Limit value alarm HI/LO Large backlit display for simultaneous visualiza- Digit increment (measuring instrument for
Unit: Switch between °C/°F tion of measured values, max. and limit values temperature): 0.1 °C
Backlit display (switchable)
Ident. No. 020 Ident. No. 041 Ident. No. 045
Min./max. temperature measuring range -33 to 500 °C -50 to 1000 °C -60 to 550 °C
Min./max. emission ratio - - 0.1-1.0
Optical focus 11:1 50:1 12:1
Rechargeable battery/battery designation Mignon AA 9 V block Micro AAA
Ident. No.
045
041
020
46135... Unit price, € O. R. O. R. O. R.
Prod. Gr. 456
Testing equipment
Video infrared temperature measuring device with integrated humidity sensor
Application: Large measured value memory (micro-SD card
For non-contact measuring of dew points and slot)
surface temperatures. Ideal for indoor climate IR temperature measuring device with integrated
specialists. Indoor climate measurements humidity sensor
Execution: Applications are displayed as JPG images with
measured values and date stamps
Double target laser
HOLD, MAX, MIN functions scope of supply and services:
Switch display between °C/F Sturdy transport case, USB cable, mains plug with
USB port USB connection, incl. temperature sensor TYP K,
small camera tripod
Error limit ±2% or ± 2°C
Advantage: Technical Data:
Min./max. temperature measuring range: -50 to
Large 2.2 inch TFT colour display 1000 °C
Input for thermocouple sensor NiCrNi (type K) Optical focus: 50:1
100
Ident. No.
46135... Unit price, € O. R.
Prod. Gr. 456
