Layer and wall-thickness measurement
Ultrasonic wall thickness measuring instruments/
Temperature and air-humidity measuring instruments

Temperature measuring instrument with universal sensor
with universal probe

Application: ƒ Error limit ± 1% ±1°C
For simple temperature measurements in industrial
applications Technical Data:
ƒ Min./max. temperature measuring range: -64 to
Execution: 1370 °C
ƒ Watertight ƒ Digit increment (measuring instrument for
temperature): 0.1 °C
ƒ HOLD function ƒ Length x width x height: 78 x 43 x 20 mm
ƒ Auto-off
ƒ Switch between °C/°F
Ident. No.
200
46105... Unit price, € O. R.
Prod. Gr. 456
Temperature measuring instruments
2-channel and 4-channel

Application: ƒ Data logger function for storing 16,000
For measuring temperature differences measurements
ƒ Backlight
Execution: ƒ Error limit ± 0.3% ±1.0°C
ƒ Displays differential temperature scope of supply and services:
ƒ USB interface Ident. No. 220: Measuring instrument, battery, 2x
ƒ Input for thermocouple, type K thermal wire type K, operating instructions
ƒ Digit increment 0.1°C from -199.9°..+199.9°C, Ident. No. 240: Measuring instrument, battery,
otherwise 1.0°C software, data cable, 2x thermal wire type K, oper-
ƒ Ident. No. 220: ating instructions
ƒ 2 simultaneous measurements
ƒ Error limit ± 0.1% ±0.7°C Technical Data: Ident. No. 220 Ident. No. 240
ƒ Ident. No. 240: ƒ Min./max. temperature measuring range: -200 to
ƒ 4 simultaneous measurements 1370 °C
Testing equipment
ƒ Configuration via software or logger keyboard ƒ Length x width x height: 184 x 64 x 30 mm
Ident. No.
220
46105... 2-channel Unit price, € O. R.
Ident. No.
240
46105... 4-channel Unit price, € O. R.
Prod. Gr. 456
Data logger for temperature and humidity

Application: ƒ High accuracy: ±0.5°C/± 3%
Ident. No. 010: For monitoring temperature, e.g. for ƒ Ident. No. 010: IP 65 protection
transport and storage ƒ Ident. No. 020: Additional measurement of rela-
Ident. No. 020: For monitoring temperature and tive air humidity and dew point
humidity, e.g. for transport and storage
scope of supply and services:
Execution: USB data cable, Windows software on CD and bat-
ƒ Large display for current value indication and tery (1x 3 V lithium type CR2032)
ƒ External temperature sensor connection Technical Data:
ƒ Battery status indication ƒ Min./max. temperature measuring range: -30 to Data logger with temperature probes
ƒ User-friendly Windows software 70 °C
ƒ Hi-Lo visual and acoustic alarm ƒ Digit increment (measuring instrument for
ƒ Memory for up to 60,000 measured values with 3 temperature): 0.1 °C
variables ƒ Temperature error limit (residual area): 0.7 °C
ƒ Measuring interval adjustable from 1 second up
to 24 hours
Min./max. humidity (rF) of measuring range - 0-99 %
IP protection class IP 65 -
010
020
Ident. No.
46200... Unit price, € O. R. O. R.
Prod. Gr. 456
Accessories for 46200 010 46200 020
40 x 3 mm, Ident. No. 103 103
46200... Temperature sensor length 3 m Unit price, € O. R. O. R.
40 x 3 mm, Ident. No. 108 108
length 8 m Unit price, € O. R. O. R.
