Lathe tools
Thread cutting programme

Thread cutting inserts sub-profile 60°
Metal cutting tools
Metal cutting tools
for internal thread cutting

Ident. No. 022, Ident. No. 021, Ident. No. 020, Ident. No.
042, 052, 054, 041, 051, 053, 055 040, 050, 058, 023, 043, 057,
056 Left, HC5630 064 059–061
Right, HC5630 Right, HC5615 Left, HC5615
Machining direction Right Left Right Left
Carbide type HC5615 HC5630 HC5630 HC5615
Vc in steel min./max. ˜ 75-110 m/ 90-120 m/ 90-120 m/ 75-110 m/
min min min min
Vc in stainless steel min./max. ˜ 70-75 m/ 80-100 m/ 80-100 m/ 70-75 m/min
min min min
Vc in non-ferrous metals min./max. ˜ 200-600 m/ - - 200-600 m/
min min
Vc in cast iron min./max. ˜ 70-80 m/ 100-110 m/ 100-110 m/ 70-80 m/min
min min min
ISO name Min./max. pitch 17737... 17737... 17737... 17737...
ID no. ID no. ID no. ID no.
11 (IR/IL) A60 0.5-1.5 mm 020 O. R. 021 O. R. 022 O. R. 023 O. R.
16 (IR/IL) A60 0.5-1.5 mm 040 O. R. 041 (O. R.) 042 (O. R.) 043 (O. R.)
16 (IR/IL) G60 1.75-3.0 mm 050 O. R. 051 (O. R.) 056 O. R. 057 (O. R.)
16 (IR/IL) AG60 3.5-5.0 mm 058 O. R. 053 O. R. 052 O. R. 059 O. R.
22 (IR/IL) N60 3.5-5.0 mm 064 O. R. 055 (O. R.) 054 O. R. 061 O. R.
Unit price, €
Prod. group 158
Thread cutting inserts sub-profile 60° HW5615
for internal thread cutting

Ident. No. 001, Ident. No. 000, Ident. No.
003, 005, 007, 002, 004, 006, 130–132
009 008 Right, HC5630
Right, HW5615 Left, HW5615 with chip breaker

Machining direction Right Left Right
Carbide type HW5615 HW5615 HC5630 with
chip breaker
Vc in steel min./max. ˜ - - 75-110 m/
min
Vc in stainless steel min./max. ˜ 60-70 m/min 60-70 m/min 80-100 m/
min
Vc in non-ferrous metals min./max. ˜ 200-600 m/ 200-600 m/ -
min min
Vc in cast iron min./max. ˜ - - 100-110 m/
min
Vc in special alloy min./max. ˜ 30-40 m/min 30-40 m/min -
ISO name Min./max. pitch 17737... 17737... 17737...
ID no. ID no. ID no.
11 (IR/IL) A60 0.5-1.5 mm 000 (O. R.) 001 (O. R.) - -
16 (IR/IL) A60 0.5-1.5 mm 002 O. R. 003 (O. R.) 130 (O. R.)
16 (IR/IL) G60 1.75-3.0 mm 004 O. R. 005 (O. R.) 132 O. R.
16 (IR/IL) AG60 3.5-5.0 mm 006 O. R. 007 (O. R.) - -
22 (IR/IL) N60 3.5-5.0 mm 008 (O. R.) 009 (O. R.) - -
Unit price, €
Prod. group 158
