Workpiece clamping
3-axis and 5-axis machine vices

Pull-down jaws
suitable for 3AX and 5AX
Application: Execution:
Pull-down jaws ƒ Hardened and polished
Jaw design Smooth
Jaws width (mm) 100
Clamp in depth (mm) 8
Ident. No.
432
28758... Price/pair, € O. R.
Prod. group 280
Clamping Technology
Round clamping heads
suitable for 3AX and 5AX
Application: scope of supply and services:
For clamping round workpieces. 4 round clamping heads with clamping screws
Execution:
ƒ For suitable torque wrench 20-200 Nm, see no.
52244
501
Ident. No.
28758... Set price, € O. R.
Prod. group 280
From Ø 30 mm to Ø 200 mm
Clamping jaws
suitable for 3AX and 5AX
Application: ƒ Ident. No. 422: Alloyed steel, can be bonded
Ident. No. 412: For clamping workpieces.
Ident. No. 422: For adapting the clamping jaws to Notes:
Cheese head screws DIN 6912 M8
the workpiece contour.
Execution:
ƒ Ident. No. 412: Untreated special steel
Jaw design Standard jaw Soft steel jaws
Jaws width (mm) 100 100
Clamp in depth (mm) 8 8
422
412
Ident. No.
28758... Unit price, € O. R. O. R.
Prod. group 280
Pins
suitable for 3AX and 5AX
Application: Execution:
Pins are used in the standard jaws. ƒ Accessories for standard jaw ref. no. 28758412

Jaw design Smooth 4-mm ring cutter 6-mm ring cutter
Clamp in depth (mm) 8 8 8
510
525
523
Ident. No.
28758... Unit price, € O. R. O. R. O. R.
Prod. group 280
Stop
suitable for 3AX and 5AX
Application: Execution:
Workpiece stop for ref. no. 28758. ƒ Stop, can be swivelled away
Ident. No.
220
28758... Unit price, € O. R.
Prod. group 280
