Page 518 - Buy Premium Tools ATORN Catalogue
P. 518
Hand tools
Cutting pliers
Cable shears
Application: Not suitable for steel wire and hard-drawn copper
For cutting single and multi-conductor copper and wire
aluminium cables.
Advantage:
Execution: Safe, ergonomic and fatigue-free working thanks
Hardened, precision-ground blades to two-component handles
Polished head Technical Data:
Narrow, riveted joint Material of the grip handle: 2-component plastic
Length (mm) 160 210
Max. medium wire Ø cutting capacity (mm) 10 12
310
320
Ident. No.
53093... Unit price, € O. R. O. R.
Prod. Gr. 597
VDE cable shears
Application: Advantage:
For cutting single and multi-conductor copper and Safe, ergonomic and fatigue-free working thanks
aluminium cables. to two-component handles
Execution: One-handed operation with integrated spring and
lock
Chrome-plated pliers Angled head relieves strain on the wrist and
Fine blade for smooth and easy cuts provides an optimum view
Ground, bolted precision joint, adjustable
Not suitable for steel wire and hard-drawn copper Technical Data:
wire Material of the grip handle: 2-component plastic
VDE type according to DIN EN 60900
Length (mm) 180 220
Max. medium wire Ø cutting capacity (mm) 18 25
420
410
Ident. No.
53093... Unit price, € O. R. O. R.
Prod. Gr. 597
Wire rope shears
Application: Advantage: General tools
For cutting finely stranded cords, hard wires and Ident. No. 019:
cables. Angled head for improved view of the working
area
Execution: One-handed operation with integrated spring
Extra-strong shearing blade and lock
Ground, bolted precision joint, adjustable Safe, ergonomic and fatigue-free working thanks Ident. No. 019
Ident. No. 050: Steel pipe arms with ergonomic to two-component handles
plastic handles
Technical Data:
Surface: Bare
Length (mm) 190 500
Max. medium wire Ø cutting capacity (mm) 7 12
Material of the grip handle 2-component plastic Polyvinyl chloride Ident. No. 050
019
Ident. No.
53300... Unit price, € O. R. 050
O. R.
Prod. Gr. 597
www.buypremiumtools.com 518
