Deburring and cleaning
Power brushes and internal cleaning brushes

Cylinder wire brushes with shank
made of steel, brass or V2A steel wire, shaft ∅ 6 mm, max. speed 15,000 rpm

Application: Execution:
Ident. No. 011–081, 111–171: For roughing, deburring, paint stripping, de- ƒ Ident. No. 091, 181: With plaited wire (number of plaits: 15)
scaling, matting and cleaning.
Ident. No. 091, 181: For machining weld seams, removing hard scale, slag, Technical Data:
underbody sealing, sand residues and for deburring. ƒ Number of pieces per packet: 5

Ident. No. 011, 031–041, 061–071, Ident. No. 021, 051, 081 Ident. No. 091, 181
111–171 Brass rotary brush Rotary brush, knotted-type steel
Steel rotary brush
Edging material Steel Brass Stainless
steel
Head Ø (mm) Width of head (mm) Wire Ø (mm) Max. rotation speed (U/ 76090... 76090... 76090...
min(rpm)) ID no. ID no. ID no.
20 4 0.15 20000 011 O. R. 021 O. R. - -
20 4 0.20 20000 - - - - 111 O. R.
30 6 0.15 20000 031 O. R. - - - -
30 9 0.20 20000 - - - - 131 O. R.
40 11 0.20 18000 041 O. R. 051 O. R. 141 O. R.
50 17 0.20 15000 061 O. R. - - - -
50 10 0.30 15000 - - - - 161 O. R.
70 18 0.30 15000 071 O. R. 081 O. R. 171 O. R.
75 13 0.50 20000 091 O. R. - - - -
75 12 0.50 20000 - - - - 181 O. R.
Unit price, €
Prod. group 792
Cylinder wire brushes with shank
nylon thread with silicon carbide, shaft ∅ 6 mm, max. speed 15,000 rpm

Application: Advantage:
For deburring and cleaning with edge rounding on ƒ Optimal adaptation to irregular surfaces due to
steel, aluminium and other non-ferrous metals and nylon fibres
for machining of punched, lathed, milled and bored ƒ High elasticity without risk of breakage paired with
tool components. a long service life
Execution: Technical Data:
ƒ Silicon carbide abrasive bristles ƒ Max. rotation speed: 15000 U/min
ƒ Due to the effect of heat on the plastic brushes, ƒ Number of pieces per packet: 5
the speed is limited to a cutting speed of 18 m/
sec.
Head Ø (mm) 50 70 50 70
Width of head (mm) 15 18 15 18
Wire Ø (mm) 0.90 0.90 0.55 0.55
Edging
material
021
011
Ident. No.
76091... Nylon with Unit price, € O. R. O. R. - -
SiC grain 180
Ident. No.
031
041
76091... Nylon with Unit price, € - - O. R. O. R.
SiC grain 320
Prod. group 792
Cylinder wire brushes for sanding block Abrasives and chemicals
Application: Execution:
No. 76092–76093: For removing rust and scale and ƒ Reducing rings for bore diameter included with no.
for grinding. 76092 081-201, no. 76093 081 and no. 76093 101.
No. 76094: For heavy demands and heavy-duty ƒ No. 76092–76093:
brush work, for removing rust and scale, for grinding ƒ Steel pipe body with pressed ring and outer
and roughing, for removing varnish and for machin- flange
ing weld seams and stone. ƒ With particularly dense material filling

No. 76092–76093 No. 76094
